The IFM EBC044 is a four-port splitter box designed for reliable connection of sensors and actuators in industrial automation systems. It provides four M8 ports with an M12 main connection and gold-plated contacts. The PBT-GF 20 housing and IP67 protection support dependable industrial operation. LED indicators provide clear switching and power status for easier maintenance.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC044 provides four M8 connection ports for compact sensor and actuator wiring. The smaller M8 interface is particularly suitable for installations where space is limited. A centralized connection point helps organize multiple field devices efficiently. This makes the product suitable for compact automation machinery.
The splitter box uses an M12 connection for the main electrical interface. This provides a practical connection between the field wiring and the automation system. Gold-plated contacts help support stable signal transmission and dependable electrical performance. The connector design is suitable for industrial sensor applications.
The housing is manufactured from PBT-GF 20 with nickel-plated brass components. This provides mechanical durability for industrial environments. IP67 protection helps protect the unit from dust and water exposure. The compact housing is suitable for installation in production machinery and automation equipment.
Four yellow LEDs indicate output or switching status, while a green LED indicates operation. This provides technicians with a quick visual indication of the connected circuits. LED monitoring can simplify commissioning and troubleshooting. The compact design also allows convenient access during maintenance.
4 M8 ports
1 M12 main connection
15...30 V DC operating voltage
1 A maximum current per port
1 A maximum total current
IP67 protection
PBT-GF 20 housing
Nickel-plated brass components
Gold-plated contacts
4 yellow LEDs
1 green power LED
Compact four-way design
Compact automation systems
Industrial sensor connections
Machine tools
Factory automation
Production machinery
Sensor and actuator wiring
Assembly equipment
Space-constrained installations
| Specification | Details |
|---|---|
| Product Code | EBC044 |
| Model | ZDO4F035MSS0000-STGH120MSS |
| Product Type | Splitter Box / Wiring Block |
| Number of Ports | 4 |
| Port Connector | M8 |
| Main Connection | M12 |
| Electrical Design | DC |
| Operating Voltage | 15...30 V DC |
| Protection Class | III |
| Maximum Current per Port | 1 A |
| Maximum Total Current | 1 A |
| Protection Rating | IP67 |
| Housing Material | PBT-GF 20 |
| Metal Material | Brass, nickel-plated |
| Tightening Torque | 0.8...1.5 Nm |
| Weight | Approx. 87 g |
| Ambient Temperature | -25...80 °C |
| Moving Temperature | -5...60 °C |
| Switching Status | 4 × yellow LED |
| Operation Status | 1 × green LED |
| Contacts | Gold-plated |
| Pack Quantity | 1 piece |
