The IFM EBC039 is an 8-port splitter box designed for centralized sensor and actuator connectivity in industrial automation systems. It features eight M12 ports and a 25 m PUR cable for extended installation distances. The robust PA housing provides IP67 and IP68 protection for demanding industrial environments. Gold-plated contacts and LED indication support reliable operation and convenient maintenance.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC039 provides eight M12 connection ports for connecting multiple sensors and actuators through a centralized field connection. This arrangement helps simplify machine wiring and improves cable organization. It allows several field devices to be connected through a single structured connection point. The eight-port configuration is suitable for automation systems with multiple sensors.
The product is supplied with a 25 m PUR cable, making it suitable for installations where the control equipment is located farther from the machine. The PUR cable provides good mechanical durability for industrial applications. It is halogen-free and suitable for dynamic installations under specified conditions. Proper cable routing and bending radius help maintain long-term reliability.
The EBC039 uses a robust PA housing designed for demanding industrial environments. IP67 and IP68 protection helps protect the electrical connections against dust and water exposure. The unit is suitable for machine tools and applications where oils and coolants may be present. Its construction provides reliable performance in harsh factory conditions.
The splitter box uses gold-plated contacts to support stable electrical signal transmission. Eight yellow LEDs indicate switching status while a green LED indicates operation. Visual status information helps technicians identify connection conditions quickly. The centralized layout also simplifies commissioning, troubleshooting and maintenance.
8 M12 connection ports
PNP electrical design
10...30 V DC operating voltage
25 m PUR cable
4 A maximum current per port
12 A maximum total current
IP67 and IP68 protection
Gold-plated contacts
PA housing
8 yellow switching LEDs
1 green operation LED
Drag-chain suitable
Halogen-free cable
Industrial automation systems
Factory automation equipment
Machine tools
CNC machinery
Sensor and actuator connectivity
Production and assembly equipment
Long-distance field-device connections
Moving machine applications
| Specification | Details |
|---|---|
| Product Code | EBC039 |
| Model | ZDO8H059MSS0025H11 |
| Product Type | Splitter Box |
| Electrical Design | PNP |
| Number of Ports | 8 |
| Connector Type | M12 |
| Connector Coding | A-coded |
| Operating Voltage | 10...30 V DC |
| Protection Class | II |
| Maximum Current per Port | 4 A |
| Maximum Total Current | 12 A |
| Protection Rating | IP67 / IP68 |
| Housing Material | PA |
| Mounting | Backplane mounting |
| Dimensions | 127 × 54 × 22 mm |
| Cable Length | 25 m |
| Cable Material | PUR |
| Cable Diameter | 8.2 mm |
| Cable Colour | Black |
| Cable Construction | Halogen-free |
| Cable Cores | 8 × 0.34 mm² + 3 × 0.75 mm² |
| Contacts | Gold-plated |
| Tightening Torque | 0.8...1.5 Nm |
| Ambient Temperature | -25...80 °C |
| Moving Temperature | -5...60 °C |
| Flexible Bending Radius | Min. 10 × cable diameter |
| Fixed Bending Radius | Min. 5 × cable diameter |
| Travel Speed | Max. 3 m/s under specified conditions |
| Torsional Strain | ±30°/m |
| Bending Cycles | >2 million |
| Drag-Chain Suitability | Yes |
| Switching Status | 8 × yellow LED |
| Operation Status | 1 × green LED |
| Items Supplied | 2 protective caps, 8 labels |
| Pack Quantity | 1 piece |
