The IFM EBC034 is an 8-port splitter box designed for reliable sensor and actuator connectivity in industrial automation systems. It features eight M12 ports and a 10 m PUR cable for flexible machine installation. The robust PA housing provides IP67 and IP68 protection in demanding environments. Gold-plated contacts and drag-chain compatibility support dependable performance in dynamic machinery.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC034 provides eight M12 connection points for connecting multiple field devices through one centralized unit. This helps reduce the complexity of machine wiring and supports organized sensor and actuator connections. The eight-port arrangement is suitable for automation systems with a larger number of field devices. It also provides convenient access for installation and servicing.
The robust PA housing is designed for demanding industrial environments. IP67 and IP68 protection helps protect the connection system from dust and water exposure. The splitter box is suitable for machine tools, factory automation and applications involving coolants and lubricants. Its durable construction supports reliable operation under mechanical stress.
The EBC034 is supplied with a 10 m PUR cable designed for industrial applications. It supports drag-chain installations and repeated cable movement under specified conditions. The product supports more than two million bending cycles and defined torsional strain. This makes it suitable for automated machines with moving components.
Gold-plated contacts help provide dependable electrical connections and stable signal transmission. A-coded M12 connectors support standardized field-device connectivity. LED indicators allow operating conditions to be monitored during machine operation. This can simplify troubleshooting and maintenance in automated production systems.
8 M12 connection ports
10 m PUR cable
4 A maximum current per port
12 A maximum total current
IP67/IP68 protection
Gold-plated contacts
Robust PA housing
Halogen-free construction
Silicone-free design
Drag-chain suitable
More than 2 million bending cycles
High mechanical durability
Industrial automation systems
Factory automation
Machine tools
CNC machinery
Production lines
Sensor and actuator connections
Coolant and lubricant applications
Moving machine systems
| Specification | Details |
|---|---|
| Product Code | EBC034 |
| Model | ZDO8H050MSS0010H19 |
| Product Type | Splitter Box |
| Number of Ports | 8 |
| Connector Type | M12 |
| Connector Coding | A-coded |
| Operating Voltage | <30 V DC |
| Protection Class | II |
| Maximum Current per Port | 4 A |
| Maximum Total Current | 12 A |
| Protection Rating | IP67 / IP68 |
| Housing Material | PA |
| Mounting | Backplane mounting |
| Dimensions | 127 x 54 x 22 mm |
| Weight | 1575.5 g |
| Cable Length | 10 m |
| Cable Material | PUR |
| Cable Diameter | 9.7 mm |
| Cable Colour | Black |
| Cable Cores | 16 x 0.34 mm² + 3 x 0.75 mm² |
| Cable Construction | Halogen-free |
| Contacts | Gold-plated |
| Locking Nut | Brass, nickel-plated |
| Tightening Torque | 0.8...1.5 Nm |
| Ambient Temperature | -25...80 °C |
| Moving Temperature | -5...60 °C |
| Flexible Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s under specified conditions |
| Maximum Acceleration | 5 m/s² |
| Bending Cycles | >2 million |
| Torsional Strain | ±30°/m |
| Drag-Chain Suitability | Yes |
| Items Supplied | 2 protective caps, 8 labels |
| Pack Quantity | 1 piece |
