The IFM EBC033 is an 8-port splitter box designed for centralized sensor and actuator connections in industrial automation. It provides eight M12 ports and a 10 m PUR cable for flexible machine installation. The robust PA housing offers IP67 and IP68 protection for demanding environments. Gold-plated contacts and drag-chain suitability support reliable industrial operation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC033 provides eight M12 ports for connecting several sensors and actuators through a centralized connection point. This helps reduce complex individual wiring and improves cable organization. The higher port count makes it suitable for machines requiring multiple field connections. It can be positioned close to sensors for more efficient machine wiring.
The splitter box features a durable PA housing designed for industrial applications. IP67 and IP68 protection helps safeguard the connection system against dust and water. Its construction is suitable for factory automation, machine tools and environments involving coolants and lubricants. The robust design supports dependable long-term operation.
The 10 m PUR cable provides extended reach for connection to automation and control equipment. The cable is halogen-free and designed for industrial installation requirements. Its drag-chain suitability supports applications involving repeated machine movement. Proper bending radius and cable routing should be maintained for reliable service.
The EBC033 uses gold-plated contacts to support stable electrical connectivity. A-coded M12 connectors provide a standardized interface for connected field devices. The connector arrangement supports easy installation and replacement. This makes the splitter box practical for maintenance-intensive industrial environments.
8 M12 ports
10 m PUR cable
4 A maximum current per port
12 A maximum total current
IP67/IP68 protection
Gold-plated contacts
PA housing
Halogen-free cable
Silicone-free construction
Drag-chain suitable
High bending-cycle capability
Backplane mounting
Industrial automation
Factory automation
Machine tools
CNC machinery
Sensor and actuator wiring
Production equipment
Coolant and lubricant environments
Moving machine applications
| Specification | Details |
|---|---|
| Product Code | EBC033 |
| Model | ZDO8H050MSS0010H11 |
| Product Type | Splitter Box |
| Number of Ports | 8 |
| Connector Type | M12 |
| Connector Coding | A-coded |
| Operating Voltage | <30 V DC |
| Protection Class | II |
| Maximum Current per Port | 4 A |
| Maximum Total Current | 12 A |
| Protection Rating | IP67 / IP68 |
| Housing Material | PA |
| Mounting | Backplane mounting |
| Dimensions | 127 x 54 x 22 mm |
| Weight | 1190 g |
| Cable Length | 10 m |
| Cable Material | PUR |
| Cable Diameter | 8.2 mm |
| Cable Colour | Black |
| Cable Cores | 8 x 0.34 mm² + 3 x 0.75 mm² |
| Cable Construction | Halogen-free |
| Contacts | Gold-plated |
| Locking Nut | Brass, nickel-plated |
| Tightening Torque | 0.8...1.5 Nm |
| Ambient Temperature | -25...80 °C |
| Moving Temperature | -5...60 °C |
| Flexible Bending Radius | Min. 10 × cable diameter |
| Bending Cycles | >2 million |
| Drag-Chain Suitability | Yes |
| Items Supplied | 2 protective caps, 8 labels |
| Pack Quantity | 1 piece |
