The IFM EBC028 is a 4-port splitter box developed for reliable sensor and actuator connectivity in industrial automation systems. It provides M12 connections with a 10 m PUR cable for extended installation flexibility. The robust PA housing offers reliable protection in demanding industrial environments. Gold-plated contacts and dynamic cable compatibility support dependable long-term performance.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC028 provides four M12 connection ports for connecting multiple sensors and actuators through a centralized field connection. This helps reduce complicated cable routing and improves the organization of machine wiring. The compact design can be installed close to field devices. It provides a practical connection solution for industrial automation systems.
The 10 m PUR cable allows the splitter box to be installed at a suitable distance from the main control equipment. This is particularly useful for larger machines and distributed sensor installations. The cable construction is designed for demanding industrial applications. Its flexible characteristics support both fixed and dynamic installations.
The EBC028 features a robust PA housing designed for harsh industrial environments. IP67/IP68 protection helps safeguard the connection system against dust and water exposure. The product is also suitable for applications involving oils and coolants. Its construction supports reliable performance under mechanical stress.
The EBC028 is suitable for drag-chain applications and repeated cable movement. It supports a specified minimum flexible bending radius and high bending-cycle performance. This makes it suitable for moving machinery, automated equipment and machine tools. Correct installation and cable routing help maintain reliable operation.
4 M12 connection ports
PNP electrical design
10 m PUR cable
10...30 V DC operating voltage
4 A maximum current per port
12 A maximum total current
IP67/IP68 protection
Gold-plated contacts
Oil and coolant resistance
Halogen-free construction
Drag-chain suitable
High bending-cycle capability
Industrial automation
Factory automation
Machine tools
CNC machinery
Moving machine applications
Sensor and actuator connectivity
Production and assembly equipment
| Specification | Details |
|---|---|
| Product Code | EBC028 |
| Model | ZDO4H059MSS0010H11 |
| Product Type | Splitter Box |
| Number of Ports | 4 |
| Connector Type | M12 |
| Connector Coding | A-coded |
| Electrical Design | PNP |
| Operating Voltage | 10...30 V DC |
| Maximum Current per Port | 4 A |
| Maximum Total Current | 12 A |
| Protection Rating | IP67 / IP68 |
| Housing Material | PA |
| Housing Design | Rectangular |
| Mounting | Backplane mounting |
| Cable Length | 10 m |
| Cable Material | PUR |
| Cable Construction | Halogen-free |
| Contacts | Gold-plated |
| Locking Nut | Brass, nickel-plated |
| Ambient Temperature | -25...80 °C |
| Moving Temperature | -5...60 °C |
| Flexible Bending Radius | Min. 10 × cable diameter |
| Fixed Bending Radius | Min. 5 × cable diameter |
| Drag-Chain Suitability | Yes |
| Bending Cycles | >2 million |
| Application | Industrial automation |
| Environmental Resistance | Oil and coolant resistant |
| Connection Interface | M12 |
| Cable Application | Fixed and flexible installations |
| Status Indication | LED |
| Housing Type | Robust industrial housing |
| Mounting Position | Backplane |
| Special Features | Silicone-free, halogen-free, gold-plated contacts |
