The IFM EBC027 is a 4-port splitter box designed for reliable sensor and actuator connections in industrial automation applications. It features M12 ports and a 10 m PUR cable for flexible installation. The robust housing provides protection for demanding industrial environments. Gold-plated contacts and visible LED indication support reliable operation and convenient maintenance.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC027 provides four M12 ports for connecting sensors and actuators through a centralized connection point. This helps simplify wiring and creates a more organized field connection layout. The compact splitter box can be positioned close to the connected devices. It is suitable for industrial automation and machine-control systems.
The integrated 10 m PUR cable provides extended reach for industrial installations. It can be useful when the field connection point is located at a considerable distance from the control equipment. The PUR cable offers suitable mechanical durability for industrial use. Proper routing helps prevent unnecessary mechanical stress during operation.
The splitter box is designed for harsh industrial environments and provides resistance to oils and coolants. Its robust housing supports reliable operation in machine tools and production equipment. The construction also offers good shock and vibration resistance. This helps the product withstand demanding operating conditions.
The EBC027 includes visible LED indication to provide quick operating information. The LEDs can be monitored during installation, commissioning and maintenance. This helps technicians identify the status of connected circuits more easily. Clear indication can also reduce troubleshooting time in automation systems.
4 M12 ports
PNP electrical design
10 m PUR cable
10...30 V DC operating voltage
4 A maximum current per port
12 A maximum total current
IP67/IP68 protection
Gold-plated contacts
Oil and coolant resistant
Robust housing
Drag-chain suitable
LED status indication
Industrial automation
Factory automation
Machine tools
CNC equipment
Production machinery
Sensor and actuator connections
Moving machine systems
| Specification | Details |
|---|---|
| Product Code | EBC027 |
| Model | ZDO4H055MSS0010H07 |
| Product Type | Splitter Box |
| Number of Ports | 4 |
| Connector Type | M12 |
| Connector Coding | A-coded |
| Electrical Design | PNP |
| Operating Voltage | 10...30 V DC |
| Maximum Current per Port | 4 A |
| Maximum Total Current | 12 A |
| Protection Rating | IP67 / IP68 |
| Housing Material | PA |
| Mounting | Backplane mounting |
| Cable Length | 10 m |
| Cable Material | PUR |
| Cable Construction | Halogen-free |
| Contacts | Gold-plated |
| Locking Nut | Brass, nickel-plated |
| Ambient Temperature | -25...80 °C |
| Moving Temperature | -5...60 °C |
| Flexible Bending Radius | Min. 10 × cable diameter |
| Fixed Bending Radius | Min. 5 × cable diameter |
| Drag-Chain Suitability | Yes |
| Bending Cycles | >2 million |
| Application | Industrial automation |
| Status Indication | LED |
| Environmental Resistance | Oil and coolant resistant |
| Shock Resistance | High |
| Vibration Resistance | High |
| Connection Interface | M12 |
| Cable Application | Fixed and dynamic installations |
