The IFM EBC025 is a compact 4-port splitter box designed for reliable sensor and actuator connections in industrial automation systems. It provides M12 connections with a 10 m PUR cable for extended installation flexibility. The robust PA housing is suitable for demanding industrial environments. Gold-plated contacts support dependable electrical connectivity.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC025 provides four M12 ports for connecting sensors and actuators through a centralized field connection. Its compact design makes it suitable for installations where available mounting space is limited. The centralized arrangement helps simplify machine wiring and cable routing. It can be integrated into various industrial automation systems.
The integrated 10 m PUR cable provides extended reach between the splitter box and the control equipment. This makes the product suitable for machines where field devices are positioned at greater distances. PUR construction provides suitable mechanical durability for industrial applications. Proper cable routing helps maintain reliable performance over extended installations.
The robust PA housing is designed for industrial environments where dust, moisture, oils and coolants may be present. IP67/IP68 protection provides additional environmental protection for the connection system. The splitter box can therefore be used in demanding machinery applications. Its construction supports reliable operation during continuous industrial use.
The EBC025 is suitable for applications involving moving cables and drag-chain systems. The cable is designed to withstand repeated bending under specified conditions. This makes the unit suitable for moving machine components and automated production equipment. Correct bending radius and installation practices should be followed.
4 M12 ports
PNP electrical design
10 m PUR cable
10...30 V DC operating voltage
4 A maximum current per port
12 A maximum total current
Gold-plated contacts
IP67/IP68 protection
Robust PA housing
Drag-chain suitable
Halogen-free construction
Industrial automation
Factory automation
Machine tools
CNC systems
Moving machinery
Sensor and actuator connections
Production equipment
| Specification | Details |
|---|---|
| Product Code | EBC025 |
| Model | ZDO4H050MSS0010H07 |
| Product Type | Splitter Box |
| Number of Ports | 4 |
| Connector Type | M12 |
| Connector Coding | A-coded |
| Electrical Design | PNP |
| Operating Voltage | <30 V AC/DC |
| Maximum Current per Port | 4 A |
| Maximum Total Current | 12 A |
| Protection Rating | IP67 / IP68 |
| Housing Material | PA |
| Mounting | Backplane mounting |
| Dimensions | 82 x 54 x 18 mm |
| Cable Length | 10 m |
| Cable Material | PUR |
| Cable Diameter | Approx. 7.5 mm |
| Cable Construction | Halogen-free |
| Contacts | Gold-plated |
| Locking Nut | Brass, nickel-plated |
| Ambient Temperature | -25...80 °C |
| Moving Temperature | -5...60 °C |
| Flexible Bending Radius | Min. 10 × cable diameter |
| Drag-Chain Suitability | Yes |
| Bending Cycles | >2 million |
| Application | Industrial automation |
| Mounting Position | Backplane |
| Connection System | M12 |
| Cable Use | Fixed and flexible applications |
