The IFM EBC021 is an 8-port splitter box developed for organized sensor and actuator connectivity in industrial automation systems. It provides eight M12 ports and a 5 m PUR cable for convenient installation. The robust PA housing is designed for demanding industrial environments. Gold-plated contacts support stable and dependable signal connections.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC021 provides eight M12 ports, allowing several sensors or actuators to be connected through one centralized splitter box. This helps reduce wiring complexity around automated machinery. The multiple-port design is suitable for installations with a higher number of field devices. It also helps maintain a cleaner and more structured cable arrangement.
The robust PA housing provides suitable mechanical protection for industrial installations. The splitter box is designed for environments where machinery may be exposed to vibration, shock, oils and coolants. Its IP-rated construction helps protect internal connections from dust and moisture. This supports reliable performance in demanding factory environments.
The 5 m PUR cable provides sufficient cable length for flexible machine installation. PUR construction offers suitable mechanical durability for industrial applications. The cable can be routed according to machine layout and installation requirements. Its suitability for dynamic applications makes it useful for moving equipment.
The EBC021 incorporates LED indication for convenient monitoring of connected circuits. Visual indication helps operators and maintenance technicians identify operating conditions quickly. This can reduce troubleshooting time during machine maintenance. Centralized connections also make inspection and replacement activities easier.
8 M12 ports
PNP electrical design
10...30 V DC operation
4 A maximum current per port
12 A maximum total current
5 m PUR cable
Gold-plated contacts
IP67/IP68 protection
Robust PA housing
Oil and coolant resistance
Drag-chain suitability
LED status indication
Industrial automation
Factory automation
Machine tools
CNC machinery
Sensor and actuator systems
Production lines
Assembly machinery
| Specification | Details |
|---|---|
| Product Code | EBC021 |
| Model | ZDO8H050MSS0005H11 |
| Product Type | Splitter Box |
| Number of Ports | 8 |
| Connector Type | M12 |
| Connector Coding | A-coded |
| Electrical Design | PNP |
| Operating Voltage | <30 V DC |
| Maximum Current per Port | 4 A |
| Maximum Total Current | 12 A |
| Protection Rating | IP67 / IP68 |
| Housing Material | PA |
| Mounting Method | Backplane mounting |
| Cable Length | 5 m |
| Cable Material | PUR |
| Cable Colour | Black |
| Cable Type | Halogen-free |
| Contacts | Gold-plated |
| Locking Nut | Brass, nickel-plated |
| Ambient Temperature | -25...80 °C |
| Moving Temperature | -5...60 °C |
| Flexible Bending Radius | Min. 10 × cable diameter |
| Fixed Bending Radius | Min. 5 × cable diameter |
| Drag-Chain Suitability | Yes |
| Application | Industrial automation |
| Connection Interface | M12 |
| Status Indication | LED |
| Housing Design | Rectangular industrial housing |
