The IFM EBC020 is a 6-port splitter box designed for centralized sensor and actuator connections in industrial automation systems. It provides multiple M12 connections with a 5 m PUR cable for flexible machine installation. The robust housing is suitable for demanding industrial environments. Gold-plated contacts provide reliable electrical connectivity and long-term performance.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC020 provides six M12 connection points for connecting sensors and actuators through a single centralized unit. This helps simplify field wiring and reduces the number of separate cable routes required. The organized connection arrangement can make machine wiring easier to inspect. It is suitable for industrial automation systems requiring multiple field connections.
The splitter box is manufactured with a robust PA housing designed for industrial applications. It can withstand common environmental stresses associated with machinery and production equipment. The construction is suitable for applications where oils and coolants may be present. This helps support dependable performance in machine-tool environments.
The integrated 5 m PUR cable provides additional flexibility when connecting the splitter box to control equipment. PUR cable construction is suitable for industrial applications requiring mechanical durability. The cable can also support dynamic installations where machine movement is involved. Proper installation helps maintain long-term cable performance.
LED indicators provide convenient visual information about the operating and switching condition of connected circuits. This allows technicians to identify the status of individual connections more easily. Centralized connections also simplify inspection and maintenance activities. The result is a more organized and service-friendly automation installation.
6 M12 ports
PNP electrical design
10...30 V DC operating voltage
4 A maximum current per port
12 A maximum total current
5 m PUR cable
Gold-plated contacts
IP67/IP68 protection
Robust PA housing
Oil and coolant resistant
Drag-chain suitable
LED status indication
Factory automation
Industrial machinery
Machine tools
CNC systems
Sensor and actuator wiring
Production equipment
Moving machine applications
| Specification | Details |
|---|---|
| Product Code | EBC020 |
| Model | ZDO6H05DMSS0005H15 |
| Product Type | Splitter Box |
| Number of Ports | 6 |
| Connector Type | M12 |
| Connector Coding | A-coded |
| Electrical Design | PNP |
| Operating Voltage | 10...30 V DC |
| Maximum Current per Port | 4 A |
| Maximum Total Current | 12 A |
| Protection Rating | IP67 / IP68 |
| Housing Material | PA |
| Cable Length | 5 m |
| Cable Material | PUR |
| Cable Colour | Black |
| Cable Construction | Halogen-free |
| Contacts | Gold-plated |
| Locking Nut | Brass, nickel-plated |
| Mounting | Backplane mounting |
| Ambient Temperature | -25...80 °C |
| Moving Temperature | -5...60 °C |
| Flexible Bending Radius | Min. 10 × cable diameter |
| Fixed Bending Radius | Min. 5 × cable diameter |
| Drag-Chain Suitability | Yes |
| Application | Industrial automation |
| Connection System | M12 field connection |
| Status Indication | LED |
| Housing Design | Compact industrial housing |
