The IFM EBC019 is a 6-port splitter box designed for reliable sensor and actuator connections in industrial automation systems. It provides organized M12 connectivity with a 5 m PUR cable for convenient field installation. The robust PA housing offers reliable protection in demanding industrial environments. Gold-plated contacts support stable and dependable electrical connections.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC019 provides six M12 connection ports for connecting multiple sensors and actuators through a centralized wiring point. This arrangement helps reduce complicated individual cable routing and keeps machine wiring organized. The compact splitter box can be positioned close to field devices for easier installation. It is suitable for various industrial automation and machine-control applications.
The splitter box features a durable PA housing designed for demanding industrial conditions. Its construction provides good resistance against mechanical stress, oils and coolants commonly found around machinery. The robust design helps maintain reliable operation during continuous machine use. This makes the EBC019 suitable for factory automation and machine-tool applications.
The EBC019 is supplied with a 5 m PUR cable that provides flexibility when connecting field devices to control equipment. The cable construction supports applications where cable movement may occur. Its drag-chain suitability makes it useful for machines with moving components. Proper cable routing can also help improve installation reliability and service life.
Gold-plated contacts help provide stable electrical connectivity between connected field devices and the automation system. The M12 connection system provides a standardized interface for industrial sensors and actuators. LED indication allows operating and switching status to be monitored easily. This can simplify troubleshooting and routine maintenance.
6 M12 connection ports
PNP electrical design
10...30 V DC operating voltage
4 A maximum current per port
12 A maximum total current
5 m PUR cable
Gold-plated contacts
IP67/IP68 protection
Robust PA housing
Oil and coolant resistant construction
Drag-chain suitable
LED status indication
Industrial automation systems
Factory automation machinery
Machine tools and CNC equipment
Sensor and actuator connection
Production and assembly machinery
Moving machine applications
Control and monitoring systems
| Specification | Details |
|---|---|
| Product Code | EBC019 |
| Model | ZDO6H057MSS0005H09 |
| Product Type | Splitter Box |
| Number of Ports | 6 |
| Connector Type | M12 |
| Connector Coding | A-coded |
| Electrical Design | PNP |
| Operating Voltage | 10...30 V DC |
| Maximum Current per Port | 4 A |
| Maximum Total Current | 12 A |
| Protection Rating | IP67 / IP68 |
| Housing Material | PA |
| Mounting | Backplane mounting |
| Cable Length | 5 m |
| Cable Material | PUR |
| Cable Colour | Black |
| Cable Design | Halogen-free |
| Contacts | Gold-plated |
| Locking Nut | Brass, nickel-plated |
| Ambient Temperature | -25...80 °C |
| Moving Temperature | -5...60 °C |
| Flexible Bending Radius | Min. 10 × cable diameter |
| Fixed Bending Radius | Min. 5 × cable diameter |
| Drag-Chain Suitability | Yes |
| Cable Construction | Suitable for dynamic applications |
| Application Environment | Industrial automation |
| Status Indication | LED indication |
| Mounting Position | Flexible / backplane installation |
