The IFM EBC008 is a 6-port splitter box designed for industrial automation and decentralized sensor wiring. It provides six A-coded M12 connections with gold-plated contacts and a central M23 connection with 19 contacts. The PA housing and IP67 protection support reliable operation in demanding industrial environments. Its compact backplane-mounted design provides an organized solution for connecting multiple field devices.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC008 provides six M12 connection ports for decentralized connection of compatible sensors and actuators. The A-coded M12 interfaces provide standardized field connections. Gold-plated contacts support reliable electrical connectivity. This arrangement helps simplify machine-level wiring.
The splitter box uses one M23 main connection with 19 gold-plated contacts. This provides a centralized interface between the splitter box and the machine control system. The connection arrangement helps organize multiple field-device signals through a single main interface. It is suitable for structured industrial wiring systems.
The EBC008 provides yellow LEDs for switching status and a green LED for operation indication. These visual indicators allow technicians to quickly check field-device status. Local indication can simplify commissioning and troubleshooting. It provides convenient monitoring without additional diagnostic equipment.
The EBC008 features a PA housing with IP67 protection and backplane mounting. Its dimensions are approximately 125 × 60 × 33 mm and the unit weighs about 256.5 g. The robust construction is suitable for demanding factory automation environments. Protective caps and identification labels are included for practical installation.
6-port splitter box
6 × A-coded M12 connections
1 × M23 main connection
19 M23 contacts
Gold-plated contacts
PA housing
IP67 protection
Yellow switching-status LEDs
Green operation LED
Backplane mounting
Factory automation
Industrial sensor wiring
Machine automation
Production equipment
Sensor and actuator connections
Control system wiring
Industrial machinery
Decentralized field wiring
| Specification | Details |
|---|---|
| Product Model | EBC008 |
| Order Code | ZDO6H05DMSS0000-00STAK190MSS |
| Product Type | Splitter Box |
| Number of Ports | 6 |
| Connector Type | M12 |
| M12 Coding | A-coded |
| M12 Contacts | 5 per connection, gold-plated |
| Main Connection | 1 × M23 |
| M23 Contacts | 19, gold-plated |
| Housing Material | PA |
| Mounting | Backplane mounting |
| Dimensions | 125 × 60 × 33 mm |
| Protection Rating | IP67 |
| Ambient Temperature | -25 to 80 °C |
| Weight | Approx. 256.5 g |
| Status Indicators | 12 yellow LEDs |
| Operation Indicator | 1 green LED |
| Included Accessories | 2 protective caps, 6 labels |
| M23 Tightening Torque | 0.8–1.5 Nm |
| M12 Tightening Torque | 0.8–1.5 Nm |
| Pack Quantity | 1 piece |
