The IFM E43381 is a launching plate designed for LR level sensors with a 3/4" NPT internal threaded connection. It provides a strong mounting interface for level measurement in tanks and process equipment. Stainless-steel construction supports reliable installation in industrial environments
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E43381 provides a flange-based mounting solution for compatible LR level sensors. It is designed for process installations where a 3/4" NPT connection is required.
The adapter incorporates a 3/4" NPT internal thread and an approximately 180 mm flange. The base plate and adapter use stainless-steel materials for durable industrial installation.
The stainless-steel construction is suitable for process environments requiring a robust mechanical mounting solution. The product is specified for tank pressures from -1 to 16 bar.
The E43381 is suitable for LR level sensor installations in tanks, vessels and industrial process systems. Its NPT threaded interface allows integration into compatible process arrangements.
Designed for LR level sensors
3/4" NPT internal thread
Stainless-steel base plate
Stainless-steel adapter
Approx. 180 mm flange diameter
Suitable for tank applications
Pressure range -1 to 16 bar
Robust mounting construction
Reliable process integration
Pack quantity of 1 piece
Industrial level measurement
Tank monitoring
Process vessels
Liquid level control
Process automation
Industrial instrumentation
| Specification | Details |
|---|---|
| Product code | E43381 |
| Product type | Coupling / launching plate |
| Model | LAUNCHING PLATE 3/4NPT |
| Sensor type | LR level sensors |
| Thread connection | 3/4" NPT internal |
| Flange diameter | 180 mm |
| Base plate material | Stainless steel 1.4571 / 316Ti |
| Adapter material | Stainless steel 1.4404 / 316L |
| Pressure range | -1 to 16 bar |
| Pack quantity | 1 piece |
