The IFM E43338 O-Ring is a compact EPDM sealing component designed for compatible process sensor and hygienic installation applications. It features a 6.5 mm inside diameter and 9.5 mm outside diameter with a 1.5 mm cross-section. The EPDM construction provides a reliable sealing solution for suitable process environments. The product is supplied in a five-piece pack for convenient installation and maintenance.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E43338 provides a precise and compact sealing interface for compatible process connections. Its dimensions are suitable for small sensor mounting points. The O-Ring helps maintain a secure seal and reduce the possibility of leakage.
The O-Ring is manufactured from EPDM material with hardness designation 70 Shore. EPDM provides a practical sealing material for suitable hygienic and process applications. The material selection makes it suitable for compatible food and beverage-related installations.
The E43338 is associated with EC 1935/2004, FDA, KTW and EHEDG approvals/listings according to distributor product information. This makes it suitable for applications requiring appropriate hygienic sealing components, subject to the exact application and compliance requirements.
The product is supplied in a pack of five pieces. This provides convenient spare parts for maintenance and servicing. The small size makes the seals easy to store and handle.
6.5 mm inside diameter
9.5 mm outside diameter
1.5 mm cross-section
EPDM material
70 Shore hardness designation
Five pieces per pack
Compact sealing design
Suitable for compatible process connections
Suitable for hygienic applications
Easy replacement and maintenance
Process sensor sealing
Hygienic process equipment
Food and beverage applications
Tank and vessel connections
Sensor adapter sealing
Maintenance and replacement applications
| Specification | Details |
|---|---|
| Product Code | E43338 |
| Product Type | O-Ring |
| Model | O-RG 6.50 x 1.50 / EPDM / 70 / SW |
| Inside Diameter | 6.5 mm |
| Outside Diameter | 9.5 mm |
| Cross-Section | 1.5 mm |
| Material | EPDM |
| Hardness | 70 Shore |
| Weight | 1.85 g |
| Pack Quantity | 5 pieces |
| Application | Process and hygienic sealing |
| Compliance / Listings | EC 1935/2004, FDA, KTW, EHEDG* |
