The E43225 is a 150 mm probe designed for compatible IFM LR level sensors. It provides a compact sensing arrangement for liquid level measurement in suitable applications. The probe can be adapted to different container requirements through shortening. Its stainless-steel construction supports reliable use in industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E43225 is a probe accessory designed for IFM LR guided wave radar level sensors. Its 150 mm length makes it suitable for compact installations where a shorter probe arrangement is required.
The probe is manufactured from stainless steel 316L / 1.4404, providing a robust construction for compatible industrial level-measurement applications. Its design allows practical integration with suitable LR level sensors.
The probe can be shortened to adapt the measurement arrangement to different container heights. This provides flexibility when installing level sensors in vessels with varying dimensions.
The E43225 is suitable for reliable detection of aqueous media and can be used with applications involving coolant emulsions, cleaning liquids and heavily polluted water. It supports easy and secure installation with compatible LR level sensors.
150 mm probe length
Designed for IFM LR level sensors
Stainless steel 316L construction
Suitable for guided wave radar
Can be shortened for installation adaptation
Suitable for aqueous media
Compact sensor accessory
Liquid level measurement
Coolant emulsions
Cleaning liquids
Water-level monitoring
Industrial process equipment
Tank-level monitoring
| Specification | Details |
|---|---|
| Product code | E43225 |
| Product type | Probe |
| Series | LR PROBE |
| Probe length | 150 mm |
| Design | For LR level sensors |
| Material | Stainless steel 316L / 1.4404 |
| Tightening torque | 4 Nm |
| Application | Level measurement |
| Suitable media | Aqueous media and compatible liquids |
| Weight | Approx. 0.063 kg |
