The E43014 is a clamp fitting designed for installing compatible capacitive level sensors and climatic tubes in process containers. It provides a 22 mm sensor connection and a 3/4" NPT external process connection. The robust construction supports secure installation and adjustable sensor positioning in industrial applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E43014 provides a practical mounting interface for compatible level-sensing components. Its clamp arrangement makes sensor installation simple and secure.
The 22 mm sensor connection supports compatible sensors and climatic tubes. The clamp design allows the required sensor immersion position to be adjusted during installation.
The adapter is constructed using stainless steel with NBR and brass components. This provides a durable mechanical connection for industrial process installations.
The E43014 is suitable for level-sensing installations in tanks, containers and industrial process equipment where a 3/4" NPT connection is required.
3/4" NPT external process connection
22 mm sensor connection
Clamp fitting design
Adjustable immersion depth
Stainless-steel construction
NBR sealing material
Brass components
Pressure rating up to 0.5 bar
Compact installation design
Pack quantity: 1 piece
Capacitive level sensors
Industrial containers
Process tanks
Liquid level monitoring
Industrial automation
Process control equipment
Factory installations
| Specification | Details |
|---|---|
| Product Code | E43014 |
| Product Type | Clamp fitting for process sensors |
| Design | Mounting adapter NPT3/4/D22 |
| Sensor Connection | Ø22 mm |
| Process Connection | 3/4" NPT external thread |
| Pressure Rating | 0.5 bar |
| Ambient Temperature | 0 to 80 °C |
| Dimensions | Ø39 × 46 mm |
| Tightening Torque | 6–8 Nm |
| Weight | 208 g |
| Materials | Stainless steel, NBR, brass |
| Pack Quantity | 1 piece |
