The E3M152 is an 11 m screened M12 connection cable designed for 3D Smart Sensor systems with analogue PAL video output. Its angled 5-pole M12 connector provides secure industrial connection, while IP67 and IP69K protection supports harsh environments. The long cable length and drag-chain suitability provide flexible installation for industrial automation and mobile machine applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The 11 m length provides extended connection capability for installations where the 3D sensor or camera is located farther from associated equipment.
The screened construction supports reliable analogue video signal transmission and helps provide stable communication in industrial installations.
The cable uses an angled A-coded 5-pole M12 connector with stainless-steel locking components for secure industrial connection.
The cable is rated IP67 and IP69K and operates from -40 °C to +80 °C. It is also suitable for drag-chain applications.
11 m connection cable
Screened cable design
M12 angled connector
A-coded connector
5 contacts
Designed for 3D Smart Sensor systems
Analogue PAL video compatibility
IP67 protection
IP69K protection
Drag-chain suitable
Mobile 3D Smart Sensors
Analogue video systems
Industrial automation
Factory automation
Machine vision
Mobile machinery
Industrial camera systems
Long-distance sensor connections
| Specification | Details |
|---|---|
| Product Code | E3M152 |
| Product Type | Connection cable |
| Model | CONNECTION CABLE M12 11M |
| Cable Length | 11 m |
| Cable Type | Screened |
| Housing Material | PUR |
| Sealing | FKM |
| Connector | 1 × M12, angled |
| Coding | A |
| Contacts | 5 |
| Locking Material | Stainless steel 303 / 1.4305 |
| Operating Voltage | < 25 V AC / < 60 V DC |
| Ambient Temperature | -40 °C to +80 °C |
| Protection Rating | IP67 / IP69K |
| Drag Chain Suitability | Yes |
| Fixed Bending Radius | ≥ 60 mm |
| Weight | 562.5 g |
| Pack Quantity | 1 piece |
