The IFM E37450 welding thermowell is a long-length, high-pressure protection solution for compatible temperature sensors. It features a 6 mm sensor connection, Ø38.1 mm welding adapter and 267 mm installation length. Manufactured from stainless steel 316L and rated up to 400 bar, it is suitable for deep process measurement points and demanding industrial temperature sensing applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E37450 is a long welding thermowell designed for temperature sensors with an EL = 350 mm sensor design.
Its 267 mm installation length and 304.8 mm bore length allow temperature sensors to reach deeper measurement points in process equipment.
With a 400 bar / 40 MPa pressure rating, it provides strong mechanical protection for high-pressure industrial process installations.
The stainless steel 316L body and Ø38.1 mm welding adapter provide durable process integration for demanding industrial applications.
Long-length welding thermowell
Designed for EL = 350 mm sensors
6 mm sensor diameter
1/2" NPS sensor connection
Suitable for G1/2 and 1/2" NPT
Ø38.1 mm welding adapter
Stainless steel 316L construction
400 bar pressure rating
267 mm installation length
13 m/s maximum permissible flow velocity
Deep tank temperature measurement
Process vessel monitoring
High-pressure process systems
Industrial pipelines
Chemical processing
Oil and gas equipment
Process automation
Industrial temperature measurement
| Specification | Details |
|---|---|
| Product Code | E37450 |
| Product Type | Welding thermowell |
| Model | THERMOWELL, D6/WELD-IN/L=300 |
| Sensor Design | EL = 350 mm |
| Pressure Rating | 400 bar / 40 MPa |
| Sensor Connection | 1/2" NPS Ø6 mm |
| Compatibility | G1/2 and 1/2" NPT |
| Process Connection | Welding adapter Ø38.1 mm |
| Material | Stainless steel 1.4404 / 316L |
| Installation Length EL | 267 mm |
| Bore Length BL | 304.8 mm |
| Max. Flow Velocity | 13 m/s |
| Weight | 1577.5 g |
| Pack Quantity | 1 piece |
| Source |
