The IFM E30150 is a robust welding adapter designed for connecting compatible process sensors to industrial and hygienic process equipment. It features a G1 Aseptoflex Vario internal thread and a 60 mm welding adapter connection. Manufactured from high-quality 316L stainless steel, it provides reliable mechanical strength and hygienic performance. The adapter is suitable for applications requiring a compact, durable and pressure-resistant sensor connection.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E30150 provides a secure welded interface between process equipment and compatible sensors. Its 60 mm welding adapter design is suitable for selected thin-wall process installations. The G1 internal thread follows the Aseptoflex Vario connection concept for compatible process sensors. This construction provides a practical and reliable sensor mounting solution in industrial environments. The adapter is designed to withstand demanding installation conditions while maintaining a stable sensor connection.
The adapter is manufactured from stainless steel 1.4435 / 316L for the wetted parts. The robust stainless-steel construction provides excellent mechanical durability for suitable industrial environments. Its surface characteristics are specified as Ra <0.4 µm and Rz 4 µm, supporting hygienic process applications. The material combination is suitable for applications where cleanable and durable process connections are required.
The E30150 provides a pressure rating of 25 bar for the sensor-to-adapter connection. It is designed for selected industrial and hygienic process applications where a secure pressure connection is required. The adapter is recommended for process walls up to 3 mm thickness. For thicker process walls, IFM recommends selecting a more suitable welding adapter.
The adapter uses a defined sealing area for the connected process sensor. An EPDM 24 × 2 mm FDA-compliant O-ring is supplied, while an FKM version is available as an accessory. These sealing options support different compatible process requirements. The adapter is suitable for applications where hygienic construction and reliable sensor sealing are important.
G1 Aseptoflex Vario internal thread
60 mm welding adapter diameter
316L stainless-steel construction
25 bar pressure rating
Suitable for industrial and hygienic applications
Smooth hygienic surface finish
Designed for thin process walls up to 3 mm
FDA-compliant sealing option
Process sensor installation
Industrial process equipment
Hygienic processing systems
Food and beverage machinery
Process tanks and vessels
Pressure and temperature monitoring systems
| Specification | Details |
|---|---|
| Product Code | E30150 |
| Product Type | Welding Adapter for Process Sensors |
| Product Designation | WELDING ADAPT D60/G1 |
| Sensor Connection | G1 internal thread |
| Connection System | Aseptoflex Vario |
| Process Connection | Welding adapter Ø60 mm |
| Pressure Rating | 25 bar |
| Maximum Pressure | 2.5 MPa |
| Recommended Wall Thickness | ≤3 mm |
| Wetted Material | Stainless steel |
| Material Grade | 1.4435 / 316L |
| Surface Roughness | Ra <0.4 µm |
| Surface Profile | Rz 4 µm |
| Sealing Type | O-ring |
| Supplied Seal | EPDM 24 × 2 mm |
| Seal Compliance | FDA compliant |
| Optional Seal | FKM 24 × 2 mm |
| Application | Industrial and hygienic |
| Installation | Welding |
| Pack Quantity | 1 piece |
| Approx. Weight | 163 g |
| Brand | IFM |
