The IFM E30147 is an FKM/FPM O-ring designed for compatible Aseptoflex process connections. It has a nominal size of 31 × 1.5 mm and is manufactured from FKM. The sealing ring provides a replaceable sealing element for suitable process sensor adapters. It is supplied in a 10-piece pack.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E30147 is specifically designated for Aseptoflex applications. Its dimensions are designed for the corresponding sealing interface. This provides a suitable replacement option for compatible process sensor connections. Correct seal selection is important to maintain process integrity.
The O-ring is manufactured from FKM, also referred to as FPM. This material provides a robust elastomer sealing solution for suitable process environments. It is suitable for applications requiring an elastomer with good temperature and chemical resistance. Actual compatibility depends on the process medium.
The O-ring has a nominal cross-section of 1.5 mm and an inner diameter of approximately 31 mm. Its outside diameter is approximately 34 mm. These dimensions provide the required geometry for compatible Aseptoflex interfaces. Accurate sizing is essential before installation.
The E30147 is useful for routine replacement of worn or damaged seals. Its 10-piece packaging provides multiple replacement units for maintenance teams. Keeping compatible O-rings available helps reduce service interruptions. The seal should be inspected during sensor installation and maintenance.
31 × 1.5 mm O-ring
FKM / FPM material
Aseptoflex compatible
Approx. 34 mm outside diameter
Reliable process sealing
Replacement sealing component
Compact design
10-piece pack
Aseptoflex process connections
Process sensor installation
Pressure sensor maintenance
Hygienic process equipment
Industrial piping
Sensor adapter servicing
| Specification | Details |
|---|---|
| Product Code | E30147 |
| Product Type | O-Ring |
| Designation | O-RG 31x1.5 ASEPTOFLEX FPM |
| O-Ring Size | 31 × 1.5 mm |
| Nominal Inside Diameter | 31 mm |
| Cross-Section | 1.5 mm |
| Approx. Outside Diameter | 34 mm |
| Material | FKM / FPM |
| Connection System | Aseptoflex |
| Seal Type | Circular O-ring |
| Installation | Sealing groove |
| Primary Function | Process connection sealing |
| Application | Process sensors |
| Weight | Approx. 5 g |
| Pack Quantity | 10 pieces |
| Brand | IFM |
