IFM E2D201 is a mounting set designed for ring light illumination units used in industrial machine vision applications. It uses a clamp mounting arrangement that allows the ring light to be positioned around the inspection target. The mounting bracket and clamp are manufactured from stainless steel for robust industrial use. The mounting set has dimensions of approximately 61.3 × 106 × 73 mm and weighs around 387 g. Screws are supplied with the mounting set to simplify installation. E2D201 provides a practical and stable solution for positioning ring illumination in automated vision systems.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
E2D201 is designed specifically for mounting compatible ring light illumination units. Ring lights are commonly used to provide controlled illumination around cameras and inspection targets. The mounting set helps position the light correctly relative to the camera and object. Proper alignment can improve illumination consistency during automated image inspection. The clamp mounting design allows the lighting unit to be adjusted during setup. This makes E2D201 suitable for industrial machine vision applications.
The clamp mounting arrangement provides a practical installation method for the ring light. It allows the lighting unit to be positioned and adjusted without requiring complicated custom brackets. During commissioning, the position can be optimized according to the inspection requirement. The mounting system helps maintain the selected position after tightening. This provides a stable foundation for consistent lighting. The design also simplifies maintenance and repositioning.
The mounting bracket and clamp are manufactured from stainless steel. This provides a robust mechanical structure for industrial illumination applications. Stainless steel is suitable for repeated handling during installation and maintenance. The construction helps support the ring light securely during machine operation. It also provides durability for common industrial environments. The mounting set is therefore suitable for long-term automated inspection equipment.
E2D201 has dimensions of approximately 61.3 × 106 × 73 mm and weighs around 387 g. Its compact structure makes it suitable for integrating ring illumination into machine vision assemblies. Screws are supplied with the mounting set for installation. The complete accessory reduces the need to design separate mounting components. It helps create a clean and stable illumination arrangement around the inspection area.
Designed for ring light illumination
Clamp mounting design
Flexible light positioning
Stainless-steel mounting bracket
Stainless-steel clamp
61.3 × 106 × 73 mm dimensions
Approx. 387 g weight
Screws supplied
Compact mounting arrangement
Suitable for machine vision
Ring light illumination
Machine vision
Automated inspection
Surface inspection
Object detection
Quality control
Packaging inspection
Industrial image processing
| Specification | Details |
|---|---|
| Product Code | E2D201 |
| Product Type | Mounting Set |
| Product Designation | MOUNTING SET RINGLIGHT |
| Application | Ring light illumination |
| Mounting Design | Clamp mounting |
| Dimensions | 61.3 × 106 × 73 mm |
| Weight | Approx. 387 g |
| Mounting Bracket | Stainless steel |
| Clamp | Stainless steel |
| Items Supplied | Screws |
| Pack Quantity | 1 pc |
| Main Function | Ring light mounting |
| Positioning | Adjustable |
| Application Area | Machine vision |
