IFM E2D109 is a mounting set designed for illumination units with a 100 × 100 mm configuration. It provides secure mechanical support for compatible lighting equipment used in automated inspection applications. The mounting system helps maintain the required illumination position during machine operation. Its industrial design supports integration into machine vision systems. It is suitable for inspection, quality control and production automation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
E2D109 is designed to provide stable mounting for compatible illumination equipment. A secure mounting arrangement helps maintain consistent lighting conditions during inspection. The accessory supports reliable installation within automated machinery. Its dedicated configuration reduces the need for improvised mounting solutions. This helps improve installation consistency and maintenance.
The 100 × 100 mm configuration is intended for compatible larger illumination units. The mounting set allows the lighting component to be positioned around the required inspection area. Proper positioning helps improve visibility and repeatability during automated image processing. It is suitable for production environments requiring controlled illumination. The design supports practical machine integration.
Designed for illumination units
100 × 100 mm configuration
Stable mechanical mounting
Suitable for machine vision
Supports accurate illumination positioning
Industrial mounting design
Machine vision
Quality inspection
Automated imaging
Production inspection
Object inspection
Industrial automation
| Specification | Details |
|---|---|
| Brand | IFM |
| Model | E2D109 |
| Product Type | Mounting Set |
| Designation | MOUNTING SET BACKLIGHT 100X100 |
| Compatible Equipment | Illumination unit |
| Illumination Size | 100 × 100 mm |
| Mounting Type | Mechanical mounting |
| Application | Machine vision |
| Product Category | Automation and Controls |
| Construction | Industrial accessory |
| Pack Quantity | 1 pc |
