The IFM E21218 is a robust mounting set designed for clamp mounting of compatible O4 photoelectric sensors. It uses a 12 mm diameter mounting rod and a stainless-steel mounting fixture for reliable mechanical support. The clamp is manufactured from high-grade stainless steel for enhanced durability and corrosion resistance. The set includes two M5 × 10 mm cylinder screws, one M5 nut and one M5 × 16 mm head cap screw. It provides a durable mounting solution for industrial automation and machine-building applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E21218 provides a complete mounting arrangement for O4 photoelectric sensors. Its clamp design holds the sensor securely while allowing positioning during installation. The 12 mm mounting rod provides a stable support structure. The mounting arrangement is suitable for production machinery and industrial automation systems. It simplifies installation and sensor replacement.
The mounting fixture is manufactured from stainless steel 1.4404 / 316L and the clamp uses high-grade stainless steel. This provides a durable all-metal mounting structure. Stainless steel is suitable for industrial environments requiring good mechanical strength and corrosion resistance. The product weighs approximately 136.5 g.
The E21218 includes two M5 × 10 mm cylinder screws, one M5 nut and one M5 × 16 mm head cap screw. These components provide the hardware required for the intended mounting arrangement. The complete set reduces installation complexity. It supports convenient sensor positioning and secure fastening. The product is supplied as one complete mounting set.
O4 photoelectric sensor mounting
12 mm mounting rod
Clamp mounting
Stainless steel 316L fixture
High-grade stainless-steel clamp
Two M5 × 10 mm screws
One M5 nut
One M5 × 16 mm screw
Robust industrial construction
O4 photoelectric sensors
Industrial automation
Machine-building
Production lines
Factory machinery
Sensor positioning
| Specification | Details |
|---|---|
| Brand | IFM |
| Model | E21218 |
| Product Type | Mounting set for photoelectric sensors |
| Order Code | E21218 |
| Product Name | O4 MOUNTING BRACKET 500 |
| Compatible Sensor | O4 photoelectric sensors |
| Mounting Type | Clamp mounting |
| Mounting Rod Diameter | 12 mm |
| Fixture Material | Stainless steel 1.4404 / 316L |
| Clamp Material | High-grade stainless steel |
| Supplied Screws | 2 × M5 × 10 mm cylinder screws |
| Supplied Nut | 1 × M5 |
| Supplied Head Cap Screw | 1 × M5 × 16 mm |
| Design | Complete mounting set |
| Sensor Adjustment | Adjustable |
| Weight | Approx. 136.5 g |
| Application | Industrial sensor mounting |
| Construction | Stainless-steel mounting assembly |
| Industrial Suitability | Yes |
| Pack Quantity | 1 piece |
