The IFM E21206 is a mounting set designed for secure clamp mounting of M18 position sensors and compatible industrial sensors. It uses a 12 mm diameter mounting rod and provides an 18.5 mm mounting diameter. The fixture and clamp are manufactured from stainless steel for robust industrial performance. Its compact design provides stable sensor positioning while allowing convenient adjustment. The mounting set is suitable for machine-building, factory automation and industrial sensor installations.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E21206 is designed for clamp mounting of compatible M18 sensors. Its 18.5 mm mounting diameter provides the required mounting clearance for the intended sensor size. The mounting arrangement securely holds the sensor while allowing adjustment during installation. It is suitable for industrial machines where reliable sensor positioning is required. The complete set simplifies sensor installation.
Both the fixture and clamp are manufactured from stainless steel. This provides strong mechanical support and improved resistance to environmental conditions compared with less durable mounting materials. The stainless-steel construction is suitable for demanding industrial installations. It provides reliable support during continuous machine operation. The complete assembly weighs approximately 112 g.
The E21206 uses a 12 mm diameter mounting rod for installation. The clamp arrangement allows the sensor to be positioned at the required detection point before tightening. This provides flexibility during machine commissioning. The mounting set can be integrated into suitable industrial mounting structures. Its compact design helps simplify sensor positioning in automated systems.
M18 position sensor mounting
18.5 mm mounting diameter
Clamp mounting
12 mm mounting rod
Stainless-steel fixture
Stainless-steel clamp
Robust industrial construction
Adjustable sensor positioning
Compact mounting arrangement
M18 position sensors
Industrial automation
Machine-building
Factory automation
Production equipment
Sensor positioning systems
| Specification | Details |
|---|---|
| Brand | IFM |
| Model | E21206 |
| Product Type | Mounting set for position sensors |
| Order Code | E21206 |
| Product Name | M18 MOUNTING SET 500 |
| Compatible Sensor | M18 position sensors |
| Mounting Type | Clamp mounting |
| Mounting Rod Diameter | 12 mm |
| Internal / Mounting Diameter | 18.5 mm |
| Fixture Material | Stainless steel |
| Clamp Material | Stainless steel |
| Design | M18 mounting set |
| Construction | Complete mounting set |
| Weight | Approx. 112 g |
| Application | Industrial sensor mounting |
| Adjustment | Adjustable clamp positioning |
| Industrial Suitability | Harsh industrial environments |
| Pack Quantity | 1 piece |
