The IFM E21202 is a compact M12 mounting set designed for secure clamp mounting of position sensors. It uses a 10 mm diameter mounting rod and a 12.2 mm mounting diameter for compatible sensor installation. The fixture is manufactured from stainless steel 316Ti, while the clamp uses die-cast zinc. The assembly provides reliable mechanical support while allowing convenient sensor adjustment. It is suitable for industrial automation, machine-building and sensor positioning applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E21202 provides a practical mounting arrangement for M12 position sensors. Its compact design makes it suitable for machine installations where available space is limited. The clamp mounting arrangement allows the sensor to be positioned according to the required detection point. The mounting rod provides a stable mechanical support structure. This simplifies sensor installation in automated equipment.
The mounting set is designed around a 10 mm round mounting profile. The 12.2 mm mounting diameter provides the required clearance for compatible sensor installation. The clamp can be adjusted during machine setup to obtain the required sensor position. This allows flexible alignment without complex mounting hardware. The design supports convenient maintenance and sensor replacement.
The fixture uses stainless steel 1.4571 / 316Ti for durable mechanical performance. The clamp uses die-cast zinc to provide secure holding force around the mounting arrangement. The product weighs approximately 48.5 g. The compact construction is suitable for continuous industrial applications. It is supplied as one complete mounting set.
M12 position sensor mounting
Clamp mounting
10 mm round mounting rod
12.2 mm mounting diameter
Stainless steel 316Ti fixture
Die-cast zinc clamp
Compact construction
Flexible sensor positioning
Easy installation and adjustment
M12 position sensors
Industrial automation
Machine-building equipment
Factory automation
Production machinery
Sensor mounting systems
| Specification | Details |
|---|---|
| Brand | IFM |
| Model | E21202 |
| Product Type | Mounting set for position sensors |
| Order Code | E21202 |
| Product Name | M12 ANGLE BRACKET 200 |
| Compatible Sensor | M12 position sensors |
| Mounting Type | Clamp mounting |
| Mounting Rod Diameter | 10 mm |
| Internal Diameter | 12.2 mm |
| Fixture Material | Stainless steel 1.4571 / 316Ti |
| Clamp Material | Die-cast zinc |
| Design | Angle bracket |
| Construction | Assembled mounting set |
| Weight | Approx. 48.5 g |
| Application | Industrial sensor mounting |
| Adjustment | Flexible clamp positioning |
| Rod Profile | Round profile |
| Industrial Suitability | Yes |
| Pack Quantity | 1 piece |
