The IFM E21140 is an industrial Ethernet connection adapter designed to connect D-coded M12 Ethernet interfaces with RJ45 connections. It features angled M12 and RJ45 connectors with four contacts each. The adapter is suitable for industrial applications and factory automation systems. With IP65/IP67 protection and an operating temperature range of -25 to 85°C, it is designed for demanding environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E21140 provides a convenient interface between industrial M12 Ethernet connections and standard RJ45 connections. This helps integrate field-level Ethernet devices with network equipment using different connector formats.
The M12 side uses D-coded technology for industrial Ethernet applications. The angled connector arrangement supports convenient cable routing in machine installations and restricted spaces.
The adapter provides IP65 and IP67 protection and is designed for ambient temperatures from -25 to 85°C. This makes it suitable for industrial automation applications with demanding environmental conditions.
M12 to RJ45 Ethernet adapter
D-coded M12 interface
Angled M12 connector
Angled RJ45 connector
Four contacts on each connection
IP65 / IP67 protection
-25 to 85°C operating temperature
Compact industrial connection solution
Industrial Ethernet networking
Factory automation
Sensor and controller connections
Machine networking
Control cabinet connections
Industrial communication systems
| Specification | Details |
|---|---|
| Product Code | E21140 |
| Product Type | Ethernet connection adapter |
| Model | INDUSTR.ETHERN.ADAPT.M12/RJ45 |
| M12 Connector | 1 × M12 |
| M12 Design | Angled |
| M12 Coding | D-coded |
| M12 Contacts | 4 |
| RJ45 Connector | 1 × RJ45 |
| RJ45 Design | Angled |
| RJ45 Contacts | 4 |
| Protection Rating | IP65 / IP67 |
| Ambient Temperature | -25 to 85°C |
| Weight | 47.5 g |
| Application | Industrial Ethernet / factory automation |
| Pack Quantity | 1 piece |
