The E20461 Angle Bracket OT/US-100 is a galvanised steel mounting accessory designed for connector units and OT applications. It provides stable mechanical positioning while simplifying sensor and connector installation. The supplied screws, nuts and washers allow the bracket to be installed without requiring separate mounting hardware.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The ANGLE BRACKET OT/US-100 is a mechanical mounting accessory designed for OT connector units and compatible installation arrangements. Its galvanised-steel construction provides a stable mounting structure for industrial automation components. The bracket measures approximately 128 × 32 × 20 mm and weighs 84 g. Supplied screws, nuts, washers and spring washers simplify installation.
Designed for OT connector units
Galvanised steel construction
128 × 32 × 20 mm overall dimensions
84 g mechanical weight
Supplied with complete basic mounting hardware
Suitable for industrial automation installations
The bracket provides a dedicated mechanical interface for mounting compatible OT connector units. Its angled structure allows the connected component to be positioned securely within the machine assembly. This helps maintain a consistent installation position during operation.
The bracket is manufactured from galvanised steel for practical industrial mounting. Its 128 × 32 × 20 mm dimensions provide a compact mechanical footprint while maintaining a rigid support structure. The 84 g weight makes it suitable for general equipment mounting.
The product is supplied with two M4 x 30 mm screws, two hexagon nuts, two washers and two spring washers. These components provide the basic fastening hardware required for the intended mounting arrangement. This reduces the need to source compatible fasteners separately.
The angled mounting format provides useful flexibility when connector units need to be positioned relative to a machine frame. It can help maintain mechanical clearance while keeping the installed component secure. The bracket is suitable for machine builders, panel installers and maintenance applications.
| Specification | Details |
|---|---|
| Product Code | E20461 |
| Product Type | Angle bracket |
| Model | ANGLE BRACKET OT/US-100 |
| Brand | IFM |
| Application | Connector unit mounting |
| Design | Angle bracket |
| Compatible Type | OT |
| Housing Material | Galvanised steel |
| Width | 32 mm |
| Height | 128 mm |
| Depth | 20 mm |
| Weight | 84 g |
| Mounting Screws | 2 × M4 × 30 mm |
| Hex Nuts | 2 |
| Flat Washers | 2 |
| Spring Washers | 2 |
| Mounting Hardware | Included |
| Installation Type | Mechanical |
| Industrial Use | Yes |
| Connector Unit Support | Yes |
| Construction | Robust metal |
| Surface Finish | Galvanised |
| Pack Quantity | 1 pc |
| Manufacturer | IFM |
| Product Status | Phase-out article |
