The IFM E12844 connecting cable is a 5 m AMP connector cable developed for mobile machinery, vehicles and CAN bus applications. Its halogen-free PUR cable construction provides a robust connection solution, while the integrated 120 Ω CAN bus termination resistor simplifies network installation. High IP65/IP67 protection and a broad operating voltage range make it suitable for demanding industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E12844 is a 5 m connecting cable with an AMP connector for reliable electrical connection in industrial, mobile and vehicle automation systems.
The AMP connector incorporates a 120 Ω CAN bus termination resistor, providing a convenient solution for compatible CAN bus installations.
The halogen-free PUR cable is designed for demanding industrial applications and provides a durable connection between electrical and automation components.
The cable is designed for harsh industrial environments and provides IP65/IP67 protection when the corresponding connector is properly connected.
AMP connector connecting cable
5 m cable length
12–24 V DC operating range
Integrated 120 Ω CAN bus termination
Halogen-free PUR cable
Ø10 mm cable diameter
IP65 protection
IP67 protection with mating connector
TPU connector housing
Silicone sealing
CAN bus networks
Mobile machines
Industrial vehicles
Factory automation
Vehicle automation systems
Machine control equipment
Industrial electrical systems
Mobile automation equipment
| Specification | Details |
|---|---|
| Product Code | E12844 |
| Model | ADOGX060-E0005H06 |
| Cable Length | 5 m |
| Cable Material | PUR |
| Cable Diameter | Ø10 mm |
| Supply Voltage | 12–24 V DC |
| Protection Class | III |
| Total Current Load | 17 A |
| Protection Rating | IP65 / IP67 |
| CAN Bus Termination | 120 Ω integrated |
| Connector | AMP connector, straight |
| Connector Housing | TPU, black |
| Seal Material | Silicone |
| Application | CAN bus and mobile applications |
| Pack Quantity | 1 piece |
