The IFM E12842 connecting cable is a 2 m AMP connector cable designed for mobile machines, vehicles and industrial automation systems. It supports 12–24 V DC operation and incorporates a 120 Ω CAN bus termination resistor inside the AMP connector. The halogen-free PUR cable, IP65/IP67 protection and robust TPU connector housing provide reliable performance in demanding industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E12842 is a connecting cable with an AMP connector designed for electrical connection in mobile machinery, vehicles and industrial automation applications.
An integrated 120 Ω CAN bus termination resistor is built into the AMP connector, making the cable suitable for CAN bus installations requiring a dedicated termination solution.
The 2 m cable is manufactured from black, halogen-free PUR and has a 10 mm cable diameter, providing a durable connection solution for industrial and mobile applications.
The cable provides IP65 and IP67 protection when the mating connector is connected. Its operating temperature range supports demanding industrial environments.
AMP connector connecting cable
2 m cable length
12–24 V DC supply voltage
Integrated 120 Ω CAN bus termination resistor
Halogen-free PUR cable
10 mm cable diameter
IP65 protection
IP67 protection with mating connector
TPU connector housing
Silicone sealing
CAN bus systems
Mobile machinery
Industrial vehicles
Factory automation
Machine control systems
Industrial automation equipment
Mobile automation applications
Vehicle electrical systems
| Specification | Details |
|---|---|
| Product Code | E12842 |
| Model | ADOGX060-E0002H06 |
| Cable Length | 2 m |
| Cable Material | PUR |
| Cable Diameter | Ø10 mm |
| Supply Voltage | 12–24 V DC |
| Protection Class | III |
| Total Current Load | 17 A |
| Protection Rating | IP65 / IP67 |
| CAN Bus Termination | 120 Ω integrated |
| Connector | 1 x AMP connector, straight |
| Connector Housing | TPU, black |
| Seal Material | Silicone |
| Ambient Temperature | -40 to +80 °C |
| Moving Application Temperature | -15 to +80 °C |
| Pack Quantity | 1 piece |
