Design & Construction

The symbol disc is manufactured in stainless steel and incorporates the Off Zero visual marking. Its compact construction is intended for use with compatible touch-sensor assemblies. The stainless-steel material provides a professional appearance suitable for industrial control environments. The symbol orientation should be considered during installation to ensure easy operator recognition. Exact dimensions and mechanical specifications should be confirmed from the manufacturer's technical documentation.

Functional Performance

The E12803 provides a visual indication for the associated touch-sensor control function. Its Off Zero symbol allows operators to identify the intended operation quickly. The component does not perform the electrical sensing function itself but supports the user interface of the control system. The stainless-steel construction provides a durable interface component for industrial applications. Correct matching with the intended touch sensor is necessary for proper installation.

Installation & Maintenance

The symbol disc should be installed into the compatible touch-sensor assembly following the appropriate installation procedure. The Off Zero marking should be correctly oriented for easy operator recognition. The mounting area should be clean and free from contaminants before assembly. Periodic inspection should verify that the disc remains secure and legible. Stainless-steel surfaces should be cleaned using suitable non-abrasive cleaning methods.

Key Features

Off Zero symbol
Stainless-steel construction
Touch-sensor compatible design
Compact symbol-disc format
Industrial operator interface
Clear visual marking
Machine-panel suitable
Durable surface construction

Benefits

Provides clear function identification
Improves operator interaction
Supports professional control-panel design
Offers a robust visual interface
Reduces operator confusion
Supports standardized machine controls
Maintains clear symbol visibility
Suitable for industrial environments

Applications

The E12803 can be used in industrial touch-sensor interfaces where the Off Zero function requires clear identification. It is suitable for automation machines, production equipment, and industrial operator panels. The stainless-steel construction makes it appropriate for applications where a durable interface component is preferred. It can support standardized control-panel layouts across industrial machinery. The product is also suitable for machine retrofits where compatible symbol identification is required.
