The IFM E12665 is a compact 0.25 m L-coded M12 power connection cable designed for space-saving industrial installations. It features angled M12 connections, five gold-plated contacts and 5 × 2.5 mm² conductors. Its IP67 protection, durable TPE construction and wide operating temperature range make it suitable for factory automation and field-level power connections.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E12665 provides a short 0.25 m connection length for compact machine layouts and installations where excess cable length should be minimized.
The angled connector arrangement supports flexible cable routing in confined areas and helps simplify connection around automation equipment.
Five gold-plated contacts and the L-coded M12 interface provide dependable electrical connectivity for compatible power applications.
IP67 protection and durable connector materials support reliable operation in demanding industrial environments.
0.25 m cable length
Angled M12 connection
L-coded design
5 gold-plated contacts
5 × 2.5 mm² cable
63 V DC operating voltage
16 A maximum current load
IP67 protection
-40 °C to +90 °C temperature range
TPE connector body
Compact automation systems
Field modules
Industrial machines
Factory automation equipment
Power connections in confined spaces
Control and automation installations
| Specification | Details |
|---|---|
| Product Code | E12665 |
| Product Type | Connection cable |
| Cable Length | 0.25 m |
| Connector | M12 |
| Connector Design | Angled |
| Coding | L-coded |
| Contacts | 5, gold-plated |
| Cable | PVC/PUR, black |
| Cable Size | 5 × 2.5 mm² |
| Operating Voltage | 63 V DC |
| Maximum Current | 16 A |
| Protection Rating | IP67 |
| Ambient Temperature | -40 °C to +90 °C |
| Connector Body | TPE |
| Locking Nut | Brass, nickel-plated |
| Sealing | FKM |
