The IFM E12661 is a robust connection cable designed for power supply and reliable connectivity in industrial automation systems. It features an L-coded M12 connection, gold-plated contacts and a durable PVC/PUR cable. With a 2 m cable length, IP67 protection and 5 × 2.5 mm² conductors, it is suitable for demanding factory automation applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E12661 provides dependable power connectivity between compatible automation components, helping maintain stable electrical connections in industrial environments.
This connection cable uses an L-coded M12 interface with a straight connector and angled connection arrangement. Gold-plated contacts support reliable signal and power transmission.
The cable is designed with a robust PVC/PUR black cable jacket, TPE moulded connector body, nickel-plated brass locking components and FKM sealing for industrial use.
The cable is suitable for factory automation, field modules and industrial power distribution applications where dependable M12 connectivity and environmental protection are required.
L-coded M12 power connection
5-pin gold-plated contacts
2 m cable length
5 × 2.5 mm² cable construction
Straight and angled connector arrangement
IP67 protection rating
Operating temperature from -40 °C to +90 °C
Maximum total current load of 16 A
Operating voltage up to 63 V DC
TPE connector body with nickel-plated brass locking
Industrial automation systems
Factory automation equipment
Field module power supply
Industrial control panels
Machine connectivity
Power distribution in automation installations
| Specification | Details |
|---|---|
| Product Code | E12661 |
| Product Type | Connection cable |
| Cable Length | 2 m |
| Connector | M12 |
| Coding | L-coded |
| Contacts | 5, gold-plated |
| Cable | PVC/PUR, black |
| Cable Size | 5 × 2.5 mm² |
| Operating Voltage | 63 V DC |
| Maximum Current | 16 A |
| Protection Rating | IP67 |
| Ambient Temperature | -40 °C to +90 °C |
| Connector Body | TPE |
| Locking Nut | Brass, nickel-plated |
| Sealing | FKM |
