The IFM E11270 is an M20 cable gland designed for reliable sealing and strain relief of connection cables. It helps protect cable entry points against moisture and contamination. The M20 × 1.5 thread provides a defined mounting interface. Its black PA housing and CR sealing material provide a practical industrial construction. The gland operates across a broad ambient temperature range of -25 to +100 °C.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E11270 provides a sealed cable-entry arrangement for compatible equipment. Its M20 × 1.5 thread allows secure installation into matching threaded openings. The CR seal supports cable-entry sealing. Proper installation helps reduce moisture and contamination ingress. The gland is suitable for industrial equipment and enclosures.
The cable gland provides mechanical strain relief at the cable entry point. This reduces direct pulling forces on internal connections. Correct tightening helps maintain the cable position. The compact design is suitable for machine and enclosure installations. It provides a simple cable-management solution.
The housing uses black PA material and the sealing element uses CR. The gland measures approximately 23 × 21 × 16 mm. Its approximate weight is 6.9 g. The specified ambient temperature range is -25 to +100 °C. The product is supplied as one piece.
M20 cable gland
M20 × 1.5 thread
Black PA housing
CR sealing material
Cable sealing
Cable strain relief
Approx. 6.9 g weight
23 × 21 × 16 mm dimensions
-25 to +100 °C range
Compact construction
Industrial cable entry
Moisture protection
Contamination protection
Threaded installation
Single-piece supply
Control cabinets
Sensor enclosures
Automation panels
Machine wiring
Industrial equipment
Cable entry points
Junction boxes
Factory automation
Electrical enclosures
Sensor systems
The E11270 provides a simple cable-entry sealing solution. Its threaded mounting simplifies installation into compatible equipment. The strain-relief function helps protect internal cable connections. The broad temperature range supports industrial applications. Its compact construction allows efficient enclosure integration.
Confirm the enclosure uses the compatible M20 × 1.5 thread. Route the cable through the gland correctly. Tighten the gland to establish the required sealing and strain relief. Check the seal for damage during maintenance. Replace worn sealing components where necessary.
| Specification | E11270 Details |
|---|---|
| Manufacturer | IFM electronic |
| Model | E11270 |
| Product type | Cable gland |
| Product name | CABLE GLAND M20 |
| Thread designation | M20 × 1.5 |
| Housing material | PA |
| Housing colour | Black |
| Sealing material | CR |
| Dimensions | 23 × 21 × 16 mm |
| Weight | Approx. 6.9 g |
| Ambient temperature | -25 to +100 °C |
| Installation | Threaded |
| Cable entry | M20 |
| Mechanical function | Cable fixation |
| Strain relief | Yes |
| Sealing function | Cable entry sealing |
| Moisture protection | Supported |
| Contamination protection | Supported |
| Product family | Cable glands |
| Accessory category | Device protection |
| Application | Industrial cable entry |
| Machine use | Supported |
| Panel use | Supported |
| Enclosure use | Supported |
| Sensor system use | Supported |
| Maintenance | Visual inspection |
| Pack quantity | 1 |
| Material category | Polymer/rubber |
| Component form | Cable gland |
| Installation type | Enclosure mounting |
