Protected Magnetic Construction

The E10754 uses hard ferrite HF 26/22 with a plastic coating and steel construction. This combination provides a mechanically protected magnetic target. The 35 mm diameter gives the component a substantial sensing surface. Its 50 mT field strength provides magnetic actuation for compatible sensors. The design is suitable for industrial installations where mechanical protection is beneficial.

Operating Temperature

The E10754 is rated for ambient temperatures from -25 to 90°C. This range covers many standard industrial automation environments. The plastic-coated construction provides an additional protective layer around the magnetic element. This can help integrate the target into machine mechanisms. Correct sensor compatibility and mounting distance should be maintained during installation.

Sensor Integration

The E10754 is designed for use with magnetic sensors. Its relatively large 35 mm diameter provides a defined physical target. The 18.7 mm length gives sufficient body depth for suitable mechanical mounting. The magnet supports concealed installation concepts within the IFM damping-magnet family. It is supplied as a single component for industrial sensor installations.

Key Features

Hard-ferrite damping magnet

HF 26/22 hard ferrite

Plastic-coated construction

Steel construction

35 mm diameter

18.7 mm length

50 mT magnetic field

65.5 g weight

-25…90°C ambient range

Magnetic sensor compatible

Long sensing range capability

Protected magnetic body

Industrial construction

Single-piece pack

Mechanical position target

Applications

Magnetic sensor actuation

Industrial automation

Machine position detection

Cylinder sensing

Mechanical movement detection

Factory automation

Protected sensor target assemblies

Machine monitoring

Industrial control systems

Position feedback mechanisms

Protected Target Design

The plastic-coated construction provides an additional protective layer around the magnetic element. This is useful where the target may experience mechanical contact or environmental exposure. The 35 mm diameter provides a substantial target geometry. The 50 mT field provides a defined magnetic response. The E10754 is therefore suited to robust industrial sensing arrangements.

Machine Position Monitoring

The E10754 can be used as a magnetic target for detecting movement or position. Its larger physical dimensions can simplify mechanical alignment. The -25…90°C range supports standard industrial machine environments. Its hard-ferrite construction is intended for durable magnetic sensing. The component can be integrated into fixed or moving machine mechanisms.
