The IFM E10193 is a mounting clamp set designed for cylindrical sensors with a 34 mm diameter. It uses a PA clamp for stable sensor fixation on C-profile rails. The set includes two M6 × 50 mm socket-head screws, two spring washers and two C-profile rail nuts. Its dimensions are approximately 58 × 70 × 29 mm with a weight of about 107.1 g. The complete mounting arrangement provides a secure and repeatable sensor installation method.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E10193 supports Ø34 mm cylindrical sensor bodies. The PA clamp provides a stable mechanical interface around the sensor. Two M6 × 50 mm screws provide secure clamping. The supplied C-profile rail nuts allow mounting to compatible profile rails. The design supports straightforward machine assembly.
The set contains two socket-head screws sized M6 × 50 mm. Two spring washers are included. Two nuts are provided for C-profile rail installation with an 11 mm slot width. The hardware allows the complete mounting arrangement to be installed without additional fixing components. One complete set is supplied.
The mounting set is useful for larger cylindrical sensor installations. Its robust PA construction provides stable mechanical support. The profile-rail mounting system permits flexible sensor positioning. The clamp can be loosened for sensor replacement. It is suitable for factory automation and machine-building applications.
E10193
Mounting Set D34
For Ø34 mm sensors
PA clamp
58 × 70 × 29 mm
107.1 g weight
2 × M6 × 50 mm screws
2 spring washers
2 C-profile rail nuts
11 mm slot width
C-profile rail mounting
Cylindrical sensor support
Secure clamping
Mechanical positioning
Complete mounting set
34 mm cylindrical sensors
Factory automation
Machine building
Profile rail systems
Industrial sensors
Conveyor systems
Packaging machinery
Production equipment
Sensor mounting
Automation equipment
The complete hardware package simplifies installation. The Ø34 mm clamp supports larger sensor bodies. Profile rail nuts allow adjustable positioning. PA construction provides strong yet lightweight mounting. The two-screw arrangement provides secure fixation.
Install the supplied rail nuts into the compatible C-profile. Position the clamp correctly. Insert and align the sensor. Tighten both M6 screws evenly. Check mechanical fixation during maintenance.
| Specification | E10193 |
|---|---|
| Product type | Mounting clamp set |
| Order number | E10193 |
| Model | Mounting Set D34 |
| Sensor diameter | Ø34 mm |
| Material | PA |
| Dimensions | 58 × 70 × 29 mm |
| Weight | 107.1 g |
| Clamp type | Cylindrical sensor clamp |
| Mounting rail | C-profile |
| Rail slot width | 11 mm |
| Socket-head screws | 2 |
| Screw size | M6 × 50 mm |
| Spring washers | 2 |
| Rail nuts | 2 |
| Nut type | C-profile |
| Mounting method | Clamp |
| Sensor retention | Mechanical |
| Application | Sensor mounting |
| Industrial use | Automation |
| Construction | PA |
| Mechanical function | Sensor fixation |
| Installation | Profile rail |
| Sensor positioning | Fixed |
| Replacement | Removable |
| Accessory category | Mounting set |
| Pack quantity | 1 set |
| Primary function | Ø34 sensor mounting |
| Hardware included | Yes |
| Mounting interface | C-profile |
| Product family | IFM mounting accessories |
