The IFM E10192 is a mounting set designed for cylindrical sensors with a 20 mm diameter. It uses a PA mounting clamp for simple and secure sensor fixation. The set includes two M6 × 30 mm socket-head screws, two spring washers and two C-profile rail nuts. The clamp weighs approximately 67.2 g and has dimensions of 35 × 50 × 29 mm. It provides a practical mounting solution for industrial sensor installations.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The E10192 is designed around a 20 mm cylindrical sensor diameter. Its clamp construction provides mechanical support around the sensor body. C-profile rail nuts allow integration with compatible profile rails. Two screws provide secure clamping. The arrangement supports quick and economical sensor installation.
The mounting set includes two M6 × 30 mm socket-head screws. Two spring washers are supplied to support secure mechanical fixation. Two nuts for C-profile rails are also included. The C-profile rail slot width is 11 mm. The complete set is supplied as one package.
The mounting set simplifies sensor installation on profile structures. Its 20 mm diameter design supports compatible cylindrical sensors. The supplied hardware reduces separate component sourcing. PA construction provides a lightweight mounting solution. The clamp allows sensor removal and replacement when required.
E10192
Mounting Set D20
For Ø20 mm sensors
PA material
35 × 50 × 29 mm
67.2 g weight
Two M6 × 30 screws
Two spring washers
Two C-profile rail nuts
11 mm rail slot width
C-profile rail mounting
Cylindrical sensor support
Secure clamping
Quick installation
One complete set
20 mm cylindrical sensors
Factory automation
Machine building
Profile rail systems
Sensor mounting
Conveyor equipment
Packaging machinery
Assembly machines
Industrial equipment
Automation structures
The complete hardware set simplifies installation. The Ø20 mm clamp provides defined sensor support. C-profile rail nuts allow flexible positioning. PA construction reduces component weight. The two-screw design provides secure fixation.
Position the clamp on the appropriate profile rail. Insert the sensor before final tightening. Align the sensing face correctly. Tighten both screws evenly. Inspect the rail nuts and screws during maintenance.
| Specification | E10192 |
|---|---|
| Product type | Mounting clamp set |
| Order number | E10192 |
| Model | Mounting Set D20 |
| Sensor diameter | Ø20 mm |
| Material | PA |
| Dimensions | 35 × 50 × 29 mm |
| Weight | 67.2 g |
| Clamp type | Cylindrical sensor clamp |
| Mounting rail | C-profile rail |
| Rail slot width | 11 mm |
| Socket-head screws | 2 |
| Screw size | M6 × 30 mm |
| Spring washers | 2 |
| Profile rail nuts | 2 |
| Nut type | C-profile rail |
| Mounting method | Clamp |
| Sensor retention | Mechanical |
| Application | Sensor mounting |
| Industrial use | Automation |
| Construction | PA clamp |
| Mechanical function | Sensor fixation |
| Installation | Profile rail |
| Sensor positioning | Fixed |
| Replacement | Removable |
| Accessory category | Mounting accessory |
| Pack quantity | 1 set |
| Primary function | Ø20 sensor mounting |
| Hardware included | Yes |
| Mounting interface | C-profile |
| Product family | IFM mounting sets |
