E10015 is a mounting clamp designed for cylindrical sensors with a 12 mm internal diameter. It has compact 30 × 30 × 18 mm dimensions and a weight of 16.9 g. The clamp is manufactured from PBT material for practical industrial sensor mounting. Two M4 × 25 mm cylinder screws are supplied. Its compact construction provides secure sensor fixation in automation equipment.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
E10015 provides mechanical fixation for cylindrical sensors. The 12 mm internal diameter defines the intended sensor size. The clamp holds the sensor securely against the mounting structure. Two M4 × 25 mm screws are supplied for installation. This simplifies mechanical assembly during machine construction.
The clamp measures 30 × 30 × 18 mm. Its 16.9 g weight makes it suitable for compact sensor installations. PBT provides the body material for the mounting clamp. The small footprint helps reduce required installation space. This is useful in dense automation assemblies.
E10015 can be incorporated into machine fixtures and sensor brackets. The clamp design allows the sensor to be held at the required position. Supplied mounting screws reduce the need for additional hardware. Its one-piece package simplifies ordering and replacement. The accessory is suitable for industrial automation applications.
12 mm internal diameter
PBT material
30 × 30 × 18 mm dimensions
16.9 g weight
Two M4 × 25 mm screws
Cylindrical sensor mounting
Compact design
Mechanical fixation
One-piece pack
Industrial sensor accessory
Cylindrical sensors
Factory automation
Machine building
Sensor mounting
Automation fixtures
Production machinery
Sensor replacement
Machine retrofits
Industrial equipment
Control-system installations
The clamp provides a dedicated mechanical seat for the sensor body. The internal diameter keeps the sensor correctly positioned. The supplied screws provide stable attachment to the mounting structure. PBT construction keeps the clamp lightweight. This supports repeatable sensor installation.
E10015 simplifies sensor replacement during machine servicing. The clamp can remain installed while the sensor is removed or repositioned. Standard M4 fixing hardware is supplied with the product. The compact structure is useful where machine space is limited. This helps reduce installation and maintenance effort.
| Specification | E10015 |
|---|---|
| Product type | Mounting clamp |
| Manufacturer | ifm electronic |
| Model | E10015 |
| Product description | Mounting clamp IF |
| Internal diameter | 12 mm |
| Material | PBT |
| Dimensions | 30 × 30 × 18 mm |
| Weight | 16.9 g |
| Supplied screws | 2 |
| Screw size | M4 × 25 mm |
| Screw type | Cylinder screw |
| Pack quantity | 1 |
| Sensor type | Cylindrical |
| Mounting method | Clamp |
| Mechanical function | Sensor retention |
| Application | Industrial automation |
| Accessory category | Mounting clamp |
| Body construction | Polymer |
| Sensor bore | 12 mm |
| Overall width | 30 mm |
| Overall height | 30 mm |
| Overall depth | 18 mm |
| Hardware included | Yes |
| Hardware quantity | 2 |
| Hardware thread | M4 |
| Hardware length | 25 mm |
| Installation type | Mechanical |
| Position retention | Yes |
| Sensor support | Yes |
| Machine integration | Yes |
