Explore performance details, construction highlights, applications, and technical information in one clear overview.
The DS2100N-1214 is a compact industrial laser barcode scanner from the Datalogic 2K Series, designed for reliable high-speed reading of 1D barcodes in automated industrial environments. This model combines standard optical resolution with a raster scanning configuration and high-performance scanning capability.
The raster scanning configuration provides a scanning pattern suited to applications where barcode positioning or label presentation can vary. The scanner is designed for automated reading applications including conveyor sorting, picking systems, automated storage and retrieval, tote reading, item tracking and packaging.
The DS2100N platform provides scan rates of up to 1,000 scans per second. Its reading range extends approximately from 30 to 310 mm, providing flexible short-range barcode reading for automated machinery and production systems.
The DS2100N-1214 combines standard resolution with a high-performance scanning configuration. This makes it suitable for applications requiring fast and consistent decoding of industrial 1D barcodes.
The NSC configuration is designed for industrial integration and includes the embedded ID-NET™ high-speed communication interface. The scanner can be configured using Datalogic's Genius™ configuration environment, while the X-PRESS™ interface provides local diagnostic and setup functionality.
The scanner supports all common 1D barcode symbologies including GS1 codes. Ambient-light immunity and a direct/90° reading window design help support reliable operation in industrial environments.
The DS2100N-1214 is suitable for automated warehousing, conveyor sorting, picking systems, automated storage and retrieval systems, tote identification, item and part tracking, process control, packaging, compliance applications and OEM equipment.
| Product Family | DS2100N - 2K Series |
|---|---|
| Model | DS2100N-1214 |
| Order Code | 930153188 |
| Product Type | Industrial laser barcode scanner |
| Scanner Type | Short-range 1D laser scanner |
| Resolution | Standard resolution |
| Scanning Configuration | Raster |
| Performance | High performance |
| Communication Configuration | NSC |
| Scan Rate | Up to 1,000 scans/s |
| Reading Range | 30 ... 310 mm |
| Barcode Type | 1D barcodes |
| Supported Codes | All common 1D codes including GS1 |
| Communication Network | ID-NET™ embedded interface |
| Configuration Tool | Genius™ |
| User Interface | X-PRESS™ |
| Reading Window | Direct and 90° reading window |
| Ambient Light Immunity | Yes |
| Application | Automated warehousing, conveyor sorting, shopfloor automation, packaging and OEM systems |
