IFM DF3110 is a ground potential distribution module designed to provide multiple connection points within industrial control cabinets. The module is configured as a GND potential module with 10 × 2.5 mm² distribution capability. It supports a 24 V DC system and is designed for DIN-rail installation. The compact 80 × 12.5 × 98.5 mm housing helps optimize control cabinet space. Push-in terminal technology simplifies connection and wiring. DF3110 is suitable for organized ground potential distribution in industrial automation and electrical control systems.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The module provides multiple ground connection points from a common potential. This helps reduce complicated individual wiring arrangements. Centralized distribution can make control cabinet wiring more structured. It is useful when several components require a common ground potential. The module supports a clean modular approach to electrical distribution. This can simplify both installation and maintenance.
DF3110 is designed for DIN-rail mounting and side-by-side installation. Its narrow housing helps maximize available cabinet space. Push-in terminals make electrical connections convenient. The integrated labelling area supports circuit identification. The module can be combined with compatible power distribution products. This makes it useful for modular automation cabinet designs.
A properly organized ground distribution architecture supports stable industrial electrical systems. DF3110 provides a dedicated distribution point for this purpose. The module is designed for an operating voltage range of 18–30 V DC. It uses protection class III architecture. Its operating temperature and IP20 protection are suited to protected control cabinet environments.
Ground potential distribution
10 × 2.5 mm² configuration
24 V DC system
18–30 V DC operating range
DIN-rail mounting
Push-in terminals
Compact 12.5 mm width
Labelling panel
Side-by-side installation
Control cabinet integration
Modular design
Space-efficient construction
Structured grounding
Maintenance-friendly wiring
Industrial automation use
Control cabinets
Ground distribution
PLC panels
Industrial automation
Machine control systems
Electrical distribution panels
Factory automation
Industrial power systems
| Specification | Details |
|---|---|
| Product Code | DF3110 |
| Product Type | Ground distribution module |
| Function | GND potential distribution |
| Design | Pot.Module GND/10 × 2.5 mm² |
| Operating Voltage | 18–30 V DC |
| Nominal Voltage | 24 V DC |
| Protection Class | III |
| Connection | Push-in terminal |
| Distribution Points | 10 |
| Conductor Size | 2.5 mm² |
| Mounting | DIN rail |
| Dimensions | 80 × 12.5 × 98.5 mm |
| Weight | Approx. 62.5 g |
| Housing | Modular |
| Installation | Control cabinet |
| Ambient Temperature | -25 to 60 °C |
| Storage Temperature | -40 to 70 °C |
| Protection | IP20 |
| EMC | EN 61000-6-2 |
| EMC Emission | EN 61000-6-3 |
| Labelling | Yes |
| Side-by-Side Installation | Yes |
| Communication | None |
| Pack Quantity | 1 piece |
