The IFM DD0296 is a compact speed monitoring evaluation unit designed for reliable monitoring of rotational and linear movement. It evaluates pulse signals from external sensors and provides switching outputs when the configured speed condition is reached. The device supports a wide operating voltage range for flexible installation. Its relay and transistor outputs allow direct integration into machine-control systems. The compact DIN-rail housing makes it suitable for industrial control cabinets.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The DD0296 monitors machine speed through pulse evaluation from connected sensors. The adjustable switching threshold allows the device to be configured for different machine speeds. It can be used for overspeed, underspeed and standstill-related monitoring functions. Startup delay and hysteresis functions help stabilize machine monitoring. The device provides a simple and cost-effective solution for rotational-speed evaluation.
The wide-range AC/DC supply allows flexible integration into machine electrical systems. Relay and transistor outputs provide both switching and diagnostic possibilities. LEDs indicate operating and switching states. Plug-in terminals simplify electrical connection and service. DIN-rail mounting provides a compact installation method for control cabinets.
Speed monitoring
Pulse evaluation
Underspeed monitoring
Overspeed monitoring
Standstill detection
Relay output
Transistor output
Wide-range AC/DC supply
Adjustable threshold
Adjustable hysteresis
Startup delay
LED indication
Compact housing
DIN-rail mounting
Sensor supply
Conveyors
Elevators
Rotating equipment
Fans
Motors
Machine drives
Material handling
Packaging machines
Speed control
Motion monitoring
Industrial automation
Machine protection
| Specification | Details |
|---|---|
| Brand | IFM |
| Model | DD0296 |
| Product Type | Speed Monitor |
| Product Family | D200 |
| Input | Pulse signal |
| Input Type | PNP |
| Pulse Channels | 1 |
| Setting Range | Model-dependent speed/frequency range |
| AC Supply | 110...240 V AC |
| DC Supply | 27 V DC nominal |
| Sensor Supply | 24 V DC class |
| Relay Output | 1 |
| Transistor Output | 1 |
| Output Function | Speed switching |
| Monitoring | Overspeed / underspeed |
| Hysteresis | Adjustable |
| Startup Delay | Adjustable |
| LEDs | Operating and switching indication |
| Connection | Screw terminals |
| Mounting | DIN rail |
| Housing | Plastic |
| Protection | IP20 |
| Dimensions | Approx. 93 × 25.4 × 109.1 mm |
| Ambient Temperature | Approx. -25...60 °C |
| Application | Motion control |
| Sensor Interface | External pulse sensor |
