Compact 2-Way Inclined Valve - 51012YAD - 1/2" is a MAROS Engineering solution for industrial automation and fluid or vacuum control. MAROS code: 51012YAD; Selected size: 2". The configuration is presented with the manufacturer-published technical characteristics relevant to this product entry.
Type: compact 2-way angle-seat valve with brass body. Size: 1/2"–1" (PN16). Pipe threads: F/F gas ISO228. Actuator types: Normally Closed (NC), Normally Open (NO), Double Acting (DA). Flow: 1/2" and 3/4" unidirectional 1→2; 1" bidirectional. The product configuration is intended for applications where the stated valve or actuator design, connection arrangement, operating range and construction materials are required.
MAROS code: 51012YAD; Selected size: 2". The selected nominal size and manufacturer code are retained exactly from the product record. Where MAROS publishes multiple versions, the applicable actuation, connection, pressure, temperature, sealing and material choices are included in the technical information below.
Type: compact 2-way angle-seat valve with brass body. Size: 1/2"–1" (PN16). Pipe threads: F/F gas ISO228. Actuator types: Normally Closed (NC), Normally Open (NO), Double Acting (DA). Flow: 1/2" and 3/4" unidirectional 1→2; 1" bidirectional. Ambient temperature: -20°/+60°C. Pilot pressure: min. 4.0 bar–max. 8.0 bar. Valve body: brass. Cylinder spacer: brass. Rotable cylinder: yes. Seal holder: brass. Piston: aluminium. Cylinder: anodized aluminium. Piston rod: stainless steel AISI 304. Rod wiper: yes. Rod guide: no. Internal O-rings: FKM. Shutter seal: FKM. PTFE/EPDM seals, valve-status indicator and ATEX certification are available on request. Maximum fluid control temperature: +100°C.
Type: compact 2-way angle-seat valve with brass body. Size: 1/2"–1" (PN16). Pipe threads: F/F gas ISO228. Actuator types: Normally Closed (NC), Normally Open (NO), Double Acting (DA). Flow: 1/2" and 3/4" unidirectional 1→2; 1" bidirectional. Ambient temperature: -20°/+60°C. Pilot pressure: min. 4.0 bar–max. 8.0 bar. Valve body: brass. Cylinder spacer: brass. Rotable cylinder: yes. Seal holder: brass. Piston: aluminium. Cylinder: anodized aluminium. Piston rod: stainless steel AISI 304. Rod wiper: yes. Rod guide: no. Internal O-rings: FKM. Shutter seal: FKM. PTFE/EPDM seals, valve-status indicator and ATEX certification are available on request. Maximum fluid control temperature: +100°C.
Compact 2-Way Inclined Valve - 51012YAD - 1/2" Compact 2-Way Inclined Valve - 51012YAD - 1/2" is an for industrial automation and pneumatic fluid or vacuum control. Maximum fluid control temperature: +100°C. Maximum fluid control temperature: +100°C.
| Feature | Specification |
|---|---|
| Type | compact 2-way angle-seat valve with brass body |
| Size | 1/2"–1" (PN16) |
| Pipe threads | F/F gas ISO228 |
| Actuator types | Normally Closed (NC), Normally Open (NO), Double Acting (DA) |
| Flow | 1/2" and 3/4" unidirectional 1→2; 1" bidirectional |
| Ambient temperature | -20°/+60°C |
| Pilot pressure | min. 4.0 bar–max. 8.0 bar |
| Valve body | brass |
| Cylinder spacer | brass |
| Rotable cylinder | yes |
| Seal holder | brass |
| Piston | aluminium |
| Cylinder | anodized aluminium |
| Piston rod | stainless steel AISI 304 |
| Rod wiper | yes |
| Rod guide | no |
| Internal O-rings | FKM |
| Shutter seal | FKM. PTFE/EPDM seals, valve-status indicator and ATEX certification are available on request |
| Maximum fluid control temperature | +100°C |
