Bar Type - BA11 Series

Bar Type - BA11 Series is a KOGANEI dty-ba11 for automated equipment applications. Its model designation identifies the selected version and should be retained for purchasing, installation and replacement so the same functional and connection characteristics are maintained.

Product Overview

The Bar Type - BA11 Series is intended for cleaning led: lights yellow when the cumulative operating time specifi ed with time selector is. The principal documented characteristics are Power supply: 24VDC ±5%. These characteristics provide the practical starting point for matching the component to the machine architecture, required motion or switching function and available installation space.

Key Product Benefits

• long time before cleaning is required
• CLEANING LED: Lights yellow when the cumulative operating time specifi ed with TIME SELECTOR is
• TIMER RESET SW: A button for canceling a lighted CLEANING LED and resetting the cumulative operating time
• Selector for specifying the cumulative operating time that controls lighting of the CLEANING LED
• Reduced expended air fl ow rate (*When using a small fl ow rate type nozzle.)
• Cleaning timer alerts you when cleaning is recommended
