IFM AL2284 is an IO-Link temperature module designed to acquire multiple temperature measurement signals in industrial automation. It provides four temperature measurement channels for connecting suitable temperature sensors. The module communicates measurement data through an IO-Link master for centralized monitoring and control. Its rugged construction makes it suitable for demanding industrial and hygienic applications. AL2284 is useful where several temperature measurement points need to be integrated into a distributed automation system.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
AL2284 allows multiple temperature channels to be connected through one decentralized IO-Link module. This can reduce the number of separate interfaces required in the control cabinet. Temperature values can be transferred to the controller for monitoring and process control. The four-channel architecture supports applications with multiple measurement points. This is useful in machinery, processing and production equipment.
The module transfers measurement information through an IO-Link communication network. Digital communication allows process values to be transmitted without traditional analog signal wiring. Diagnostic and identification information can also be managed through the IO-Link system. This improves visibility of field measurement devices. The module can be integrated into modern PLC-based control architectures.
The module is designed for field-level installation near temperature measurement points. Its industrial housing and connector system support reliable machine integration. High environmental protection helps it operate in demanding locations. The decentralized architecture can simplify wiring and commissioning. AL2284 is therefore suitable for automated temperature monitoring systems.
4 temperature channels
IO-Link temperature measurement
Digital process data transmission
IO-Link diagnostics
Sensor identification
Industrial M12 connectivity
IP-rated housing
Distributed field installation
Compact module architecture
Machine-level temperature monitoring
PLC integration
Suitable for process monitoring
Machine temperature monitoring
Process equipment
Food processing
Packaging machinery
Industrial ovens
Cooling systems
Heating systems
Fluid temperature monitoring
Production equipment
Automated process control
| Specification | Details |
|---|---|
| Product Code | AL2284 |
| Product Type | IO-Link temperature module |
| Measurement Channels | 4 |
| Function | Temperature measurement |
| Communication | IO-Link |
| IO-Link Revision | Refer to datasheet |
| Transmission | Refer to datasheet |
| Sensor Type | Supported temperature sensors per datasheet |
| Process Data | Temperature values |
| Diagnostic Data | IO-Link diagnostics |
| Connector | Industrial M12 |
| Number of Ports | Refer to datasheet |
| Operating Voltage | Refer to datasheet |
| Protection | IP69K / model-specific |
| Ambient Temperature | Refer to datasheet |
| Housing | Industrial field module |
| Mounting | Machine / backplane mounting |
| Input Channels | 4 temperature inputs |
| Digital Communication | Yes |
| Sensor Identification | IO-Link |
| Parameterization | IO-Link |
| Status LEDs | Yes |
| Housing Material | Refer to datasheet |
| Sealing Material | Refer to datasheet |
| Pack Quantity | 1 piece |
