The AC2458 CompactLM12 2DI-Y 2DO T is a compact AS-Interface module combining digital inputs and outputs for distributed machine control. Two digital inputs support monitoring of field sensors and machine states. Two digital outputs provide local control of suitable actuators and switching devices. Its compact LM12 construction supports installation close to the automation process. The module provides a practical solution for machines requiring both signal acquisition and actuator control in one field device.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The AC2458 provides a combination of two digital input channels and two digital output channels. This mixed I/O architecture allows one compact module to perform both monitoring and control functions. The module communicates through the AS-Interface network and can be integrated with an appropriate AS-i master. Its distributed architecture helps reduce centralized wiring requirements. It is suitable for compact machine automation and modular production systems.
The two digital inputs can be used for discrete sensor and machine-state signals. The two outputs can provide switching commands for compatible actuators. Combining both functions helps simplify field-level network architecture. The module can be positioned near the controlled process to reduce cable routing. This approach supports flexible machine design and efficient automation integration.
Commissioning can be performed through the connected AS-i master and network configuration. Device addressing supports identification within the AS-i network. Input and output states can be monitored from the automation system during operation. Maintenance personnel can inspect field connectors and wiring directly at the distributed module. Regular checks help identify loose connections, cable damage, or abnormal signal behavior.
2 digital inputs
2 digital outputs
DI-Y input configuration
CompactLM12 design
AS-Interface connectivity
Distributed I/O architecture
Digital sensor monitoring
Local actuator control
Compact field installation
M12-oriented connectivity
Reduced control wiring
Machine automation integration
Assembly machines
Packaging equipment
Conveyor automation
Material handling
Machine status monitoring
Actuator switching
Production lines
Industrial automation
Sensor networks
Modular machine systems
Factory equipment
Distributed control applications
| No. | Specification | Details |
|---|---|---|
| 1 | Product Code | AC2458 |
| 2 | Product Family | AS-Interface CompactLine |
| 3 | Product Type | CompactLM12 mixed I/O module |
| 4 | Digital Inputs | 2 DI-Y |
| 5 | Digital Outputs | 2 DO |
| 6 | Network | AS-Interface |
| 7 | Communication | Digital AS-i communication |
| 8 | Installation | Decentralized |
| 9 | Field Interface | M12 |
| 10 | Signal Type | Digital |
| 11 | Input Function | Sensor/state monitoring |
| 12 | Output Function | Actuator switching |
| 13 | Process Data | Digital input/output |
| 14 | Addressing | AS-i device addressing |
| 15 | Master Compatibility | AS-i master systems |
| 16 | Parameterization | Network configuration |
| 17 | Diagnostics | Device/network status |
| 18 | Power Architecture | AS-i system supply |
| 19 | Housing | Compact industrial housing |
| 20 | Mounting | Field/machine mounting |
| 21 | Installation Environment | Industrial |
| 22 | Wiring Architecture | Distributed field wiring |
| 23 | Maintenance | Field-level servicing |
| 24 | System Integration | PLC via AS-i master |
| 25 | Manufacturer | ifm electronic |
