The AC2252 is a SmartL25 AS-Interface module designed for four digital inputs and four digital outputs. It provides a compact interface for connecting industrial sensors and actuators to an AS-i network. The module is intended for structured control cabinet installation. Its balanced I/O configuration supports machines requiring both monitoring and control functions. The design helps reduce individual PLC wiring and simplifies distributed automation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Four digital inputs collect feedback from field devices. Four outputs provide switching signals for suitable actuators. The AS-i network carries process information between the module and controller. SmartL25 construction supports compact DIN-rail installation. LED indication assists with commissioning and troubleshooting. The module can be integrated into a wide range of industrial automation systems.
Input sensors send digital states into the module. These states are transferred to the AS-i master. Controller output commands are transmitted back through AS-i. The module activates the corresponding digital outputs. The connected actuators respond according to the machine program. This creates a two-way distributed I/O interface.
Channel LEDs make it easier to identify signal states. AS-i indication helps determine network health. Sensor wiring should be checked if expected input states are missing. Actuator wiring should be inspected when output commands are not reflected in the field. Regular terminal checks help prevent connection failures. DIN-rail mounting simplifies maintenance activities.
Four digital inputs
Four digital outputs
AS-i communication
SmartL25 design
DIN-rail mounting
Compact cabinet installation
Digital sensor integration
Digital actuator control
LED diagnostics
Distributed I/O architecture
Machine automation
Packaging systems
Conveyors
Assembly lines
Material handling
Industrial fixtures
Sensor monitoring
Actuator control
Process equipment
Factory automation
| No. | Specification | Details |
|---|---|---|
| 1 | Product Code | AC2252 |
| 2 | Product Family | SmartL25 |
| 3 | Product Type | Digital I/O module |
| 4 | Network | AS-Interface |
| 5 | I/O Configuration | 4DI / 4DO |
| 6 | Inputs | 4 digital |
| 7 | Outputs | 4 digital |
| 8 | Input Technology | Digital |
| 9 | Output Technology | Digital |
| 10 | Sensor Interface | Digital sensors |
| 11 | Actuator Interface | Digital actuators |
| 12 | Communication | AS-i |
| 13 | Addressing | AS-i addressing |
| 14 | Process Data | Digital I/O |
| 15 | Installation | Control cabinet |
| 16 | Mounting | DIN rail |
| 17 | Housing | SmartL25 |
| 18 | Status LEDs | I/O and network |
| 19 | Diagnostics | AS-i/channel |
| 20 | Wiring | Cabinet wiring |
| 21 | Controller | AS-i master |
| 22 | Environment | Industrial |
| 23 | Maintenance | I/O inspection |
| 24 | Serviceability | DIN-rail replacement |
| 25 | Typical Use | Industrial machine control |
